REFRIGERATION
tools
Threaded Insert Tool Kit
Ideal for installing refrigerator hardware or anything
requiring a flush threaded mounting in sheet metal.
When properly installed, inserts are guaranteed not
to pull out or shake loose.
No. 142-1229
• Installs in sheet metal from .020" to .200" thick
• Metal storage case
• Kit includes: Insert gun (No.142-1236),

6-32 insert head (No.142-1234),

8-32 insert head (No.142-1235),

10-24 insert head (No.142-1230),

10-32 insert head (No.142-1231),
1
⁄ 4 -20 insert head (No.142-1232),

5
⁄ 16 -18 insert head (No.142-1233)

ULTIMATE TEMPERATURE
CLAMP
This unique device is 3 tools in 1—thermometer,
digital PT chart for 65 refrigerants, and pipe
clamp. Provides instant readings and is excellent
for superheat and subcool calculations.
Insert Gun No. 142-1603
• For reading temperature and pressure on
refrigerant lines
• Clamp fits 1 ⁄ 4 " to 1 1 ⁄ 8 " (6mm to 29mm) tubing
• Features hold and auto-off after 5 minutes
• Includes 2 AAA batteries
No. 142-1236 No. 253-1243 Replacement AAA battery
Insert Heads
Place insert in gun and put
into pre-drilled hole.
Tool sets insert into hole
by crimping non-threaded
portion of insert.
No.
No.
No.
No.
142-1235 8-32
142-1230 10-24
142-1231 10-32
142-1232 1 ⁄ 4 -20
©2012 Franklin Machine Products
Threaded Inserts
• Zinc-plated steel
• Sold in quantities of 100
Insert is now permanently
attached with a 360°
contact fit.
Deep threads provide a
stronger mount than sheet
metal screws.
No.
No.
No.
No.
No.
142-1150
142-1151
142-1152
142-1153
142-1485
8-32 thread
10-24 thread
10-32 thread
1
⁄ 4 -20 thread
5
⁄ 16 -18 thread
Metal Punch Kit
No. 142-1051
• Punches steel, copper, aluminum, and plastic
up to 14 gauge
• Punches 7 hole sizes:
3
⁄ 32 ", 1 ⁄ 8 ", 5 ⁄ 32 ", 3 ⁄ 16 ", 7 ⁄ 32 ", 1 ⁄ 4 ", 9 ⁄ 32 "
• Plastic box
PANEL LIFTING TOOL
This unique tool is designed so two people can easily
lift and carry one or more large panels. Can be
positioned anywhere on the panels to allow comfort
when carrying, regardless of any difference in height.
• Automatically clamps to one or more panels as the
tool is lifted
• Use with walk-in panels, doors, steel, framed
windows, plywood, gypsum board, or just about
any large panel
• No weight limit—will hold any liftable weight
• Plastic-coated forged steel
• Sold by the pair
No. 142-1452
For panels 1 ⁄ 4 " to 4 1 ⁄ 2 "
(6mm to 114mm) thick
• Blue
No. 142-1460 For panels 2 1 ⁄ 4 " to 5 1 ⁄ 2 "

(57mm to 140mm) thick
• Black
