REFRIGERATION
Electronic Commutation (EC) FAN Motors
Electronic commutation fan motors save energy and generate less heat in the refrigerator,
thus reducing the need for more compressor cycles.
EC FAN MOTOR
by WELLINGTON
No. 124-1336
• 1-speed
• Replaces most shaded pole motors
• 5 ⁄ 8 " (16mm) shaft
• 1800 RPM
• CCW rotation
• 120 volt, 0.34 amp, 16 watt
• Wellington no. ECR92JA12
• 1-speed
• Replaces shaded
pole motors
• 3 ⁄ 4 " (19mm) shaft
• 115 volt
• 1550 RPM
• CCW rotation
• Includes power cord
No. 124-1337 0.23 amp, 9 watt
• Wellington no. ECR01A0241
No. 124-1338 0.31 amp, 12 watt
• Wellington no. ECR01A0242
No. 124-1339 0.41 amp, 16 watt
• Wellington no. ECR01A0243
EC FAN MOTORS
by WELLINGTON
WALL
RING BASKET
No. 124-1332
• For mounting Wellington motors and
8" (203mm) fan blades (Nos. 124-1333
and 124-1334)
• 10 1 ⁄ 4 " (260mm) flange
• Plastic
• Wellington no. 1MS100088
About 50% More Efficient Than Shaded Pole Motors
EC motors are actually DC motors with an electronic commutation control to make them turn.
Fan Motors
AXIAL FAN
No. 253-1439
• 115 volt, 20/22 amp
• 4 3 ⁄ 4 " (121mm) square
• Black plastic
CONDENSER FAN MOTOR
No. 124-1392
• 115 volt, 0.62 amp, 9 watt
• 1550 RPM
• ¼-20 thread shaft
• CW rotation from shaft end
• Includes oil port
EVAPORATOR
fan MOTOR
No. 505-1009
• 115 volt, 2.1 amp
• 1 ⁄ 15 HP
• 1550 RPM
• 5 ⁄ 16 " (8mm) shaft diameter
• CW rotation from shaft end
Phone: 800-257-7737
Condenser
Fan Motor
No. 500-1017
• For most Manitowoc ® ice machines
• 208/230 volt, 1.5 amp
• 1050 RPM
• 1 ⁄ 2 " (13mm) shaft diameter
• CW rotation from lead end
EVAPORATOR
fan MOTOR
No. 124-1406
• 208/230 volt, 1.1 amp
• 1550/1300 RPM
• 5 ⁄ 16 " (8mm) shaft diameter
• CW rotation from shaft end
• Fasco no. D1126
EVAPORATOR
FAN MOTOR
No. 124-1481
• Replaces A. O. Smith model 9721,
EMR model 9664, Fasco model D1127,
and Mars model 01127 motors
• 115/230 volt, 1.1/0.6 amp
• 1550 RPM
• 5 ⁄ 16 " x 2 5 ⁄ 8 " (8mm x 67mm) shaft
• Reversible rotation
• Includes run capacitor
EVAPORATOR
fan MOTOR EVAPORATOR
FAN MOTOR
No. 124-1405
• 115 volt, 2.1 amp
• 1550 RPM
• CW rotation from shaft end
• 5 ⁄ 16 " x 3" (8mm x 76mm) long D shaft diameter
• Includes four 10-32 thread nuts
• Fasco no. D1124 No. 124-1419
• 208/230 volt
• 1650 RPM
• 5 ⁄ 16 " (8mm) shaft diameter
• CW rotation from shaft end
• Includes run capacitor
• Fasco no. 71639383
24-Hour Fax: 800-255-9866
273
