REFRIGERATION
Universal Ballasts
Electronic ballasts are an investment in efficiency and cost-savings. Can be custom-programmed easily and eliminate the need for complex
wiring by controlling multiple fluorescent lamps at a time. Produce a quiet operation and minimal heat inside their circuits—preventing
overheating and socket destruction.
INSTANT START UNIVERSAL
BALLAST
No. 253-1323
• For operating one or two F96T8 96" or one
F96T8HO 96" lamps
• 120 to 277 volt at 50 or 60Hz
• 109 watt maximum load, 0.91 amp maximum current
• 32° to 158°F (0° to 70°C) operating temperature range
• For indoor or outdoor use
BALLAST
No. 294-1062
• For operating one or two F32T8, F40T8 lamps
• 120 volt
• 0.97 amp
• Includes 3 molex connectors
BALLAST
No. 253-1394
• For operating one or two F17T8, F25T8, F32T8,
F32T8 (30W/28W/25W), F40T8, FBO3IT8 lamps
• 120 to 277 volt at 50 or 60Hz
• 0.50 amp maximum current
• For outdoor use
BALLAST
No. 253-1325
• For operating one or two F40T8, F58T8, F70T8,
F48T12/HO, F48T10, F48T12/VHO, F60T12/HO,
F60T10, F60T12/VHO, F72T12/HO, and one F72T10,
F72T12/VHO, F96T12/HO lamps
• 120 volt
• 27" (686mm) wire leads
• Rapid start
UNIVERSAL BALLASTS
• For indoor or outdoor use
• 120 to 277 volt at 50 or 60Hz
• – 22° to 158°F (– 30° to 70°C) operating temperature range
No. 253-1320 100 watt maximum load
• 0.85 amp maximum current
• For operating one or two F25T8 36", F32T8 48",
and F40T8 60" bi-pin lamps
No. 253-1322 150 watt maximum load
• 1.38 amp maximum current
• For operating one F72T8HO, F72T10VHO, F96T12HO,
and F96T12VHO, and one or two F48T8HO, F60T8HO,
F48T10VHO, F60T10VHO, F48T12HO, F60T12HO,
and F72T12HO lamps
No. 253-1321 155 watt maximum load
• 1.35 amp maximum current
• For operating one or two F58T8 60" and F70T8 72"
medium bi-pin lamps
For Ballast Cross Reference, see page 269.
270
fmponline.com
