REFRIGERATION
Pivot HINGES
Self-Closing Pivot Hinge
Assembly with Versatile
Mounting Brackets
A
Self-Closing
Pivot
Top Hinges Pivot Hinges
• Used with bottom hinges
• Chrome-plated steel
• Kason no. 1522 • 3 ⁄ 16 " (84mm) overall height
• Chrome-plated steel
• CHG no. R75
No. 123-1192
No. 123-1193 No. 123-1199 1 5 ⁄ 8 " (41mm) “A” dimension
No. 123-1198 1 7 ⁄ 8 " (48mm) “A” dimension
For left-hand doors
For right-hand doors
5
• Chrome-plated steel
• CHG no. R56
• Standard Keil no. 2856
Top
Mounting
Brackets
No. 123-1203
Top right, bottom left
No. 123-1202
Top left, bottom right
(not shown)
Bottom
Mounting
Brackets
No. 123-1205
Bottom left
No. 123-1204
Bottom right
(not shown)
Bottom Spring
Cartridge
Bottom Hinges
• Used with self-closing pivot top hinges
• Chrome-plated steel
• Kason no. 1521
No. 123-1194
No. 123-1195
For left-hand doors
For right-hand doors
HINGE ASSEMBLIES
• Includes top and bottom hinges,
spring cartridge (No. 123-1206),
and instructions
No. 214-2006 For left-hand doors
• Continental Refrigerator no. 20209
No. 214-2007 For right-hand doors
• Continental Refrigerator no. 20208
No. 123-1206
• Left or right
• Includes mounting hardware
• Kason no. 1556
Bottom
Pivot Brackets
No. 123-1208
Top right, bottom left
(not shown)
No. 123-1207
Top left, bottom right
Top Pivot Brackets
No. 123-1210
Top right
Internal Door
Closer
Hinge Bracket Kit
No. 123-1196
• Mounts in 1 of the 4 combinations
• Chrome-plated steel
• Kit includes: 2 hinge brackets,
2 hinge pins,
2 door bushings (not shown)
Phone: 800-257-7737
No. 123-1209
Top left (not shown)
No. 124-1134
• Used inside door panels
• For top or bottom of left- or
right-hand doors
• 4 3 ⁄ 4 " (121mm) overall height
• 1" x 1" x 3 1 ⁄ 2 "
(25mm x 25mm x 89mm) body
24-Hour Fax: 800-255-9866
