1 2 |
10 3 ⁄ 4 "
( 273mm)
|
3 ⁄ 4 "
( 19mm)
|
4 5 ⁄ 8 "
( 117mm)
|
|
10 1 ⁄ 4 "
( 260mm)
|
5 ⁄ 8 "
( 16mm)
|
5 1 ⁄ 8 "
( 130mm)
|
Latch and Strike
No. 122-1046
• Chrome-plated
• Replaces Grand Rapids no. 4772-1
|
|
4 5 ⁄ 8 "
( 117mm)
|
Latches and Strikes |
|||
3 |
• Chrome-plated
• Kason no. 538
|
|||||||||
|
Latches and Strikes
• Chrome-plated
• Replaces National Lock nos. 59-1105, C8765 and Standard Keil nos. 2830, 9176, 9177
• CHG no. R35
Straight Handle
1. No. 122-1040 With cylinder lock 1. No. 122-1042 Without cylinder lock
|
No. 122-1051 No. 122-1050 |
With cylinder lock Without cylinder lock |
10 5 ⁄ 8 "
( 270mm)
|
3 3 ⁄ 8 "
( 86mm)
5 5 ⁄ 8 "
( 143mm)
|
||||||
Offset Handle |
||||||||||
|
2. No. 122-1044 With cylinder lock 2. No. 122-1045 Without cylinder lock
Latch with Brass Roller and Insulated Offset Handle
3. No. 134-1045 Without cylinder lock
• Ideal for use on warmers
Replacement Parts
No. 122-1043 Strike only No. 122-1041 Cylinder lock only
|
10 1 ⁄ 2 "
( 267mm) 5 ⁄ 8 "( 16mm)
4 5 ⁄ 8 "
( 117mm)
|
Latches and Strikes
No. 122-1055
• Without cylinder lock
• Chrome-plated
• Kason no. 531
|
|
Latches and Strikes
• Chrome-plated
• Kason no. 174
|
9 1 ⁄ 4 "
( 235mm)
|
3 ⁄ 4 "
( 19mm)
|
||||
|
9 1 ⁄ 4 "
( 235mm)
Latch and Strike
No. 122-1047
• Chrome-plated
• CHG nos. R26, WP107
|
3 ⁄ 4 "
( 19mm)
3 3 ⁄ 4 "
( 95mm)
|
Straight Handle
No. 122-1029 With cylinder lock No. 122-1028 Without cylinder lock
Offset Handle
No. 122-1032 With cylinder lock No. 122-1031 Without cylinder lock
Replacement Parts No. 122-1030 Strike only
|
Latch and Strike
No. 122-1221
• Chrome-plated
• Kason no. 533D
|
3 3 ⁄ 4 "
( 95mm)
|
