PLUMBING
dipperwells & accessories
Dipperwell
Installation Kit
No. 117-1152
• For use with side mounted dipperwell
(No. 117-1339)
• Kit includes all the components for water
line and drain connections
replacement
Overflow Tube
No. 117-1338
• For use with side mounted
dipperwell (No. 117-1339)
• Brass
SIDE MOUNTED dipperwell
No. 117-1339
• Can be attached to the side of an ice cream cabinet or soda fountain
• 10" W x 6" H x 3" D
• 5 ⁄ 8 " OD rubber bumper allows excess water to be tapped off
• 1 ⁄ 4 " inlet tube with adaptor
• Includes 1" NPS drain, overflow tube, and mounting screws
• Stainless steel
• ETL Sanitation listed to NSF standard 2
10"
6"
©2010 Franklin Machine Products
replacement
Faucet
No. 117-1136
• For use with dipperwell
(No. 117-1060)
• 1 ⁄ 4 " flare male inlet
• Stainless steel
Side Mounted Dipperwell
replacement
Overflow Tube
No. 117-1135
• For use with dipperwell
(No. 117-1060)
• 1" OD x 2 15 ⁄ 16 " H
• White PVC
No. 117-1060
• Can be attached to the side of an ice cream
cabinet or soda fountain
• Includes stainless steel shut-off valve at the
base of inlet tube
• Includes overflow tube
• 1 ⁄ 4 " flare male inlet
• 1" NPS drain
11"
• 2 GPM
maximum output
• Stainless steel
4"
©2010 Franklin Machine Products
