PLUMBING
drains & Sink Baskets
B
“A” dimension is referred
to as drain size.
Actual OD is
approximately 1 ⁄ 4 " larger.
C
A
©2012 Franklin Machine Products
1
Spin and
Seal Drain
2
Heavy Cast Drain Assemblies
• Includes lock nut and washer
REF
No. ITEM No.
A
B
C
DRAIN SIZE FLANGE LENGTH
Brass
1
⁄ 2 " NPS
1 1 ⁄ 8 "
1 102-1000
1 102-1004
1" NPS
2"
1 102-1007
1" NPS
2"
1 102-1009
1" NPS
2"
1 102-1011
1 1 ⁄ 2 " NPS
3"
1 102-1014
1 1 ⁄ 2 " NPS
3"
Nickel-Plated Brass
1
1 102-1001
⁄ 2 " NPS
1 1 ⁄ 8 "
3
⁄
1 102-1003*
4 " NPS
1 1 ⁄ 2 "
1 102-1005
1" NPS
2"
1 102-1008
1" NPS
2"
1 102-1010
1" NPS
2"
1 102-1012
1 1 ⁄ 2 " NPS
3"
1 102-1015
1 1 ⁄ 2 " NPS
3"
1 102-1017
2" NPS
3 3 ⁄ 8 "
Stainless Steel
2 102-1065
1 1 ⁄ 2 " NPS
2 7 ⁄ 8 "
* Lock nut and washer not included
2"
1 1 ⁄ 2 "
3 1 ⁄ 4 "
4"
1 1 ⁄ 2 "
3"
2"
1 3 ⁄ 4 "
1 1 ⁄ 2 "
3 1 ⁄ 4 "
4"
1 1 ⁄ 2 "
3"
2"
1 5 ⁄ 16 "
heavy-duty waste
style drain
No. 100-1056
• Fits 3" sink opening
• 2" NPS male x 1 1 ⁄ 2 " female outlet
• 1 1 ⁄ 4 " overflow outlet
• Nickel-plated bronze body
• Stainless steel strainer and flange
• Nickel-plated bronze threaded clean-out plug
100
Sink basket screws into drain, providing a better
seal when closed and better straining when open.
No. 102-1067
• Fits 3 1 ⁄ 2 " sink opening
• 1 1 ⁄ 2 " NPS outlet
• 4 1 ⁄ 2 " top diameter
• Stainless steel
Flat
Strainer
Drain
No. 102-1068
• Fits 3", 3 1 ⁄ 2 " or 4" sink openings
• 1 1 ⁄ 2 " NPS outlet
• 4 3 ⁄ 8 " top diameter
• 2" high
• Stainless steel
No. 102-1113 Replacement sink basket
Basket
Sink Drains
• Fits 3 ⁄ 2 " sink opening
• 1 1 ⁄ 2 " NPS outlet
• 4 1 ⁄ 2 " top diameter
• Drain body and sink basket are
stainless steel
1
No. 102-1097 Stainless steel
No. 102-1064 300 series

stainless steel
Drain WASHERS
No.
No.
No.
No.
No.
102-1023 1 ⁄ 2 " NPS
102-1115 3 ⁄ 4 " NPS
102-1025 1" NPS
102-1026 1 1 ⁄ 2 " NPS
102-1027 2" NPS
fmponline.com
Free Flow
Drain
No. 102-1096
• Fits 3 1 ⁄ 2 " sink opening
• 2" NPS
• 4 1 ⁄ 2 " top diameter
• 2 3 ⁄ 8 " high
• Cast brass with stainless steel top
Drain
LOCK NUTS
No.
No.
No.
No.
No.
102-1018 1 ⁄ 2 " NPS
102-1019 3 ⁄ 4 " NPS
102-1020 1" NPS
102-1021 1 1 ⁄ 2 " NPS
102-1022 2" NPS
