Cooking Accessories |
cooking accessories |
SHELVING |
|
SPECIFY WIDTH
( left to right)
|
SPECIFY DEPTH( front to back)
Custom-made Wire Shelving
Standard-Duty
• 5 ⁄ 16 "( 8mm) OD frame and support bar
• 1 ⁄ 8 "( 3mm) OD crosswires, 3 ⁄ 4 "( 19mm) spacing
No. 300-1018 Nickel-plated No. 300-1019 Chrome-plated No. 300-1020 Green plastic-coated No. 300-1021 Stainless steel No. 300-1055 White epoxy-coated No. 300-1056 Green epoxy-coated No. 300-1057 Silver epoxy-coated
Heavy-Duty
• 3 ⁄ 8 "( 10mm) OD frame and support bar
• 3 ⁄ 16 "( 5mm) OD crosswires, 3 ⁄ 4 "( 19mm) spacing
No. 300-1030 Nickel-plated No. 300-1031 Chrome-plated No. 300-1032 Green plastic-coated No. 300-1033 Stainless steel No. 300-1058 White epoxy-coated No. 300-1059 Green epoxy-coated No. 300-1060 Silver epoxy-coated
To order, specify: 1. Quantity 2. Item no. and finish 3. Exact dimensions— depth( front to back) x width( left to right). Refer to drawing.
A written confirmation must accompany all orders for custom-made items. Please indicate the exact dimensions and any special features. Confirmations can be sent by fax or mail.
Note: Special configurations and accessories are available. Please call for more details.
Important: Nickel, chrome, and stainless steel shelving recommended for ovens. Epoxy- and plastic-coated, and stainless steel shelving recommended for coolers or freezers where condensation exists.
For an easy-to-use order form, see the back of the catalog. HIGH TEMPERATURE SILICONE GASKETS & Sealant
1 |
5 ⁄ 8 "( 16mm)
9 ⁄ 16 "
( 14mm)
|
7 ⁄ 16 "
( 11mm)
|
|
DOOR GASKET
No. 280-2019
• 17 '( 5M) long
• Rated to 600 ° F( 316 ° C) maximum
|
Compression Gaskets
• Rated to 450 ° F( 232 ° C) maximum
1. No. 127-1089 25 '( 8M) length 1. No. 127-1093 100 '( 30M) length 2. No. 127-1091 25 '( 8M) length
3 ⁄ 4 "( 19mm)
3 ⁄ 16 "
( 5mm)
Sponge Gasket
No. 127-1087
• 15 '( 5M) length
• Rated to 450 ° F( 232 ° C) maximum
High temperature silicone sealant
No. 127-1060
• 2.8 oz( 83mL) tube
• Rated to 400 ° F( 204 ° C)
• Gray
86 fmponline. com
