Technical Detail
=
=
=
=
=
=
=
=
=
22 gauge galvanised steel radiating surface
Fully insulated panel to optimise performance and minimise heat losses
through the rear panel surface
Fits into standard “T” bar suspended ceiling
Slimline model SL/C suitable for perimeter heating
Standard finish: White textured
24 gauge galvanised steel backing plate
1.5m heat resisitant cable attached
Thermal over-load protection
Mounting heights for ceiling products: 2.4m min - 4.0m max
Installation
Attach the brackets
directly to the ceiling
Alternatively the cassette
may be suspended with wire
Lower cassette
onto bracket supports
Place cassette
adjacent to brackets
Slide cassette
into position
Product Codes
Product Code
Wattage
Dimensions
Product
Price ex VAT (£)
2C-250
250
595 x 595 x 25mm
125.00
5C-500
500
1195 x 595 x 25mm
165.00
SL/C-300
300
1195 x 295 x 25mm
124.00
E700 IN-2
700
1195 x 592 x 30mm
180.00
call our sales team on 01592 760928 or email [email protected]
