The ideal product to prevent downward heat loss under wood and laminate floors
ECOMAX-LITE
t
h
e
r
m
a
l
i
n
s
u
l
a
t
i
o
n
FOR USE WITH ECOFILM
ECOMAX-LITE Thermal Insulation is an extruded
polystyrene insulation material for use below wood
or laminate floors in conjunction with ECOFILM
underfloor heating elements. ECOMAX-LITE is
available in 6mm thick sheets and is manufactured
from recycled material free from ozone depleting
chemicals.
Produced from a closed cell construction foamed
polystyrene it has excellent thermal insulation
properties. It MUST be used below ALL ECOFILM
heating systems.
Each board covers 1m2, simply order the number of
boards you require for your chosen floor area adding
approximately 10% for cutting wastage.
Where threshold height limitations permit in
conservatories we recommend installing a
double layer of ECOMAX-LITE insulation.
Floor Construction
ECOMAX-LITE reduces downward heat losses to the
sub-floor ensuring more of the heat is transferred through
the finished floor surface.
1
3
2
4
1. Laminate/Timber Floor
2. Polyester Vapour Barrier
3. ECOFILM Elements
4. ECOMAX-LITE Thermal Insulation
5. Wood/Concrete Sub Floor
5
Features
=
=
=
=
=
=
=
6mm thick
Excellent moisture resistance
Excellent sound insulation
Levels small floor imperfections
Suitable for most floor constructions
Easy to work with – cut with knife
Lightweight and easy to handle
Technical Detail
= Dimensions – 800mm x 1250mm x 6mm
(1m2 coverage per sheet)
= Material: Closed cell foamed polystyrene
= Density: 40Kg/m3
= Thermal conductivity – 0.035W/moK
Product Codes
Product
Code
Description
Price ex
VAT (£)
EL06
ECOMAX-LITE Thermal Insulation
( 800mm x 1250mm x 6mm )
5.50
call our sales team on 01592 760928 or email [email protected]
