Simplicity in Control
FLEXELTOUCH
FLOOR SENSING THERMOSTAT
= The new Flexel-Touch is designed to be the simplest to use electric floor heating control available.
= The Flexel-Touch comes packed with innovative features to optimise your comfort and minimise running
costs with the simplest touch screen interface.
= A large full colour backlit touch screen provides simple programming by guiding you through program
setup and adjustment - no need for any complicated instruction manual.
Features and Benefits
Energy Monitor
Shows how much energy is being used and when
Attractive styling
Choice of thermostat finishes and display options.
Easy to use
Touch-screen interface makes any adjustment easy
Easy Installation
Choice of 4 factory preset program schedules to get your
heating working quickly.
Intuitive Programming
Simple to use graphical display with user configured
screen colours
Specification
Maximum load: 16 Amps, 230V AC, 3680W
Electrical Protection: Class II
External Sensor Compatibility:10K,12K or 15K Ohms @25oC
Floor Sensor Type: NTC, 3M cable
Dimensions H/W/D: 90 x 90 x 19 mm
Installation Depth: 22mm
Warranty: 3 years
Approvals: EN 60730-1:2003
Product
Code
Description
Price
ex VAT (£)
ET16W
White Touchscreen Thermostat
85.00
ET16S
Energy Efficient
Optimise comfort and save energy with multiple
time and temperature settings
20
Silver Touchscreen Thermostat
88.00
ET16B
Black Touchscreen Thermostat
88.00
RAS
Optional Remote Auxiliary Sensor
16.00
SPARE PART ONLY- Each thermostat is supplied with a 3m Floor Probe.
ET16PR
Replacement Floor Probe
visit www.flexel.co.uk for detailed product info & installation tips
15.00
