Floor Construction
Kit Contents
ECOFILMPRO is
a complete heating solution in a box for most
laminate and engineered hardwood floors.
Simply select the floor coverage required from kit sizes
available: 5m2, 10m2, 15m2 & 20m2
= Roll of 500mm wide ECOFILM
Before laying ECOFILMPRO on either a suspended
wooden floor or concrete sub-floor it is necessary to
install a layer of ECOMAX-LITE thermal insulation.
This will minimise heat losses and ensure quicker
heat-up times for the floor. It will also act as a means of
sound deadening which is required for laminate floors.
Unroll the ECOFILMPRO and cut to required lengths.
= Heating Element Connection Crimps
Cover the floor area with elements laid in parallel.
Elements should NEVER overlap. Connect the wiring
harness to the heating element with the supplied crimping
tool and insulate the connector with mastic adhesive tape.
= Cold Tail Connection Leads (Brown & Blue)
= Mastic Insulation Tape
= Green Polyester Tape Disks
Cover the total floor including non heated areas with a
layer of Polyester Vapour Barrier (PVB) before laying the
chosen floor covering.
= Ratchet Crimping Tool
= Full Installation Instructions
= 10 Year Guarantee Certificate
1
Product Codes
3
2
Product
Code
Description
Price ex VAT
(£)
EPRO-5
5m2 ECOFILMPRO kit
158.90
EPRO-10
10m2 ECOFILMPRO kit
258.90
EPRO-15
15m2 ECOFILMPRO kit
358.90
EPRO-20
20m2 ECOFILMPRO kit
458.90
4
5
1. Laminate/Timber Floor
2. Polyester Vapour Barrier
3. ECOFILM Heating Elements
4. ECOMAX-LITE Thermal Insulation
5. Wood/Concrete Sub Floor
Required Accessories
Product
Code
Description
Price
ex
VAT
(£)
EL06
ECOMAX-LITE Thermal Insulation
( 800mm x 1250mm x 6mm )
5.50
PVB12
Polyester Vapour Barrier ( 1m x 12m )*
28.00
PVB25
Polyester Vapour Barrier ( 1m x 25m )**
47.00
ET16W
White Touch Screen Thermostat
85.00
TH131
Manual Analogue Thermostat
50.00
TH232
Digital Programmable Thermostat
68.00
ADT50
Adhesive Tape ( 50mm x 50m )
6.40
For Thermostat
information
see page 20 & 21
There are sufficient accessories in each kit to complete
the product installation in a single regularly shaped room.
If you choose to use a single kit to cover multiple rooms
additional accessories may be required.
Additional Accessories
Description
Price ex VAT
(£)
CRIMP10
10 x Connection Crimps
4.50
CTBL10
Cold Tail Leads ( Blue )
1.5mm2 x 10m
6.50
CTBR10
Cold Tail Leads ( Brown )
1.5mm2 x 10m
6.50
MASTIC1
1000mm x 101mm Mastic Tape
20.00
GTD20
* 1m x 12m of PVB covers 10m2 of floor area
** 1m x 25m of PVB covers 22m2 of floor area
Product
Code
20 x Green Termination Disks
1.20
call our sales team on 01592 760928 or email [email protected]
