Flexel catalogue 2014 | Seite 9

Floor Construction

Product Codes
Area to be
heated (m²)

Product Code

Wattage
(W)

Price ex VAT
(£)

1.2 - 1.9

CK1

225

76.48

2.0 - 2.9

CK2

350

95.96

3.0 - 3.9

CK3

525

107.95

4.0 - 4.9

CK4

700

Suspended Floors - When fitting ECOFLEX cable to a
timber sub-floor it is essential that standard precautions
to stabilise the floor are taken to prevent floor movement.
All chipboard & timber floorboards must be covered with
either ECOMAX insulated tile backer board or 18mm
Plywood.

141.46

5.0 - 6.4

CK5

875

2 x CK3

1050

215.90

7.5 - 8.9

CK3 + CK4

1225

249.41

9.0 - 9.9

2 x CK4

1400

282.92

10.0 - 10.9

CK4 + CK5

1575

301.44

11.0 - 11.9

2 x CK5

1750

319.96

12.0 - 13.4

2 x CK3 + CK5

1925

375.90

13.5 - 14.4

3 x CK4

2100

424.38

14.5 - 15.9

2 x CK4 + CK5

2275

442.90

16.0 - 17.4

CK4 + 2 x CK5

2450

461.42

17.5 - 18.9

3 x CK5

2625

479.94

19.0 - 20.4

2 x CK3 + 2 x CK5

2800

535.86

20.5 - 21.9

CK2 + 3 x CK5

2975

575.90

22.0 - 23.4

2 x CK4 + 2 x CK5

3150

602.88

23.5 - 24.9

CK4 + 3 x CK5

3325

621.40

1

159.98

6.5 - 7.4

2

3

4

5

1. Tile/Stone Floor
2. Tile Adhesive
3. ECOFLEX Cable
4. ECOMAX Thermal Insulation/
18mm WPB Plywood
5. Suspended Timber Floor/Concrete Sub Floor

Accessories
Product
Code

Description

Price
ex VAT
(£)

TB06

6mm insulated tile backer board (600mm x 1200mm)

16.40

TB10

10mm insulated tile backer board (600mm x 1200mm)

16.40

TBSW

(25mm) Fixing Screws & (35mm) Washers (pack of 50)

16.60

ET16W

White Touch Screen Thermostat (16A)

85.00

ET16S

Silver Touch Screen Thermostat (16A)

88.00

ET16B

Black Touch Screen Thermostat (16A)

88.00

TH232

Digital programmable Thermostat (15A)

68.00

Concrete Floors - For optimal performance it is
recommended before laying ECOFLEX cable, a layer of
ECOMAX insulated tile backer board is fitted. This will
minimise heat losses & ensure quicker heat-up times for
the floor. ECOFLEX can be laid directly onto an
un-insulated floor, however this will increase running costs
and heat-up times.

For Thermostat
information
see page 20 & 21

Technical Detail
=
=
=
=
=

Approximate Installed Loading - 150W/m2
Diameter – less than 3mm
230V supply
Twin conductor cable
1 x 3m cold tail connection lead

call our sales team on 01592 760928 or email [e-mail]
