The quick and simple to install
solution for all tile and stone floors
ECOFLOOR®
underfloor heating mat
ECOFLOOR® Underfloor Heating Mats are a combination of a heating cable attached to a fibreglass mesh scrim that
makes installation easy. The mat can simply be rolled out onto the floor saving precious time. The mats
have double sided tape on the underside so they can easily be fixed to any clean surface.
ECOFLOOR® Underfloor Heating Mats have a twin conductor cable simplifying installation with a single 3m “cold tail”
connection. Available in 2 standard power dissipations: 150Watts/m2 mats are suitable for internal applications
including kitchens and bathrooms & 200Watts/m2 mats are available for conservatory use or areas where high heat
losses occur.
Features
= Approved to EN60335-2-96 as required by the 17th
Edition Wiring Regulations ( BS7671:2008 )
= Two heat outputs – 150W/m2 and 200W/m2
= Quick installation – simply roll out the mat & fix to floor
= Continuous metallic earth screen to ensure electrical safety
= Suitable for tile, stone, slate and marble floor finishes
= Low build height – minimal floor height build up
= Suitable for use in wet areas
= EMC safe
Technical Detail
=
=
=
=
Max Power Loading - 150W/m2 or 200W/m2
Diameter 3.0mm – 4.0mm
230V supply
Twin conductor heating cable with single
3m “cold tail” connection lead
Lifetime Warranty
6
visit www.flexel.co.uk for detailed product info & installation tips
