The versatile space heating sol u t io n
E CO S U N
High Output Radiant Panels
Ecosun Radiant Panels are an ideal way of providing thermal comfort in commercial and industrial buildings.
They are specifically designed for high level mounting. They can be horizontally ceiling mounted with an
auxilliary frame or suspended on drop rods or chains.They are only 60mm deep and typical applications
include large volume spaces where conventional warm air convection system heating systems would be
uneconomic . These include; Supermarkets, Gymnasiums, Showrooms, Factories and Warehouses.
Features
Ecosun radiant panels offer many advantages over conventional warm air heating systems. These include:
= Localised Heating- only warm the area required
e.g. work stations
= Suspended or ceiling mounted. Ecosun panels
provide totally usable floor & wall space & reduce
the risk of damage or vandalism.
= Higher ventilation and air extract rates do not
significantly effect the radiant performance of
Ecosun panels which primarily warm the fabric
of the heated area.
=
Radiant heating does not cause air convection
currents, therefore minimising dust movement &
provides a clean draft free environment.
=
Ecosun panels are constructed using a rod heating
element encapsulated within a special aluminium
extrusion profile. The surface area of the aluminium
profile is treated with a silicating process which
substancially increases its surface area and its ability to emit heat. The result is a high efficiency, low
mantenance heater suitable for commecial
and industrial environments.
= Gentle radiant heat results in improved comfort
conditions at lower inside ambient temperature.
Providing comfort conditions at lower running costs.
32
visit www.flexel.co.uk for detailed product info & installation tips
