The ideal product to prevent downward heat loss under wood and laminate floors
ECOMAX-LITE
t
h
e
r
m
a
l
i
n
s
u
l
a
t
i
o
n
FOR USE WITH ECOFILM
ECOMAX-LITE Thermal Insulation is an extruded
polystyrene insulation material for use below wood
or laminate floors in conjunction with ECOFILM
underfloor heating elements. ECOMAX-LITE is
available in 6mm thick sheets and is manufactured
from recycled material free from ozone depleting
chemicals.
Produced from a closed cell construction foamed
polystyrene it has excellent thermal insulation
properties. It MUST be used below ALL ECOFILM
heating systems.
Each board covers 1m2, simply order the number of
boards you require for your chosen floor area adding
approximately 10% for cutting wastage.
Where threshold height limitations permit in
conservatories we recommend installing a
double layer of ECOMAX-LITE insulation.
Floor Construction
ECOMAX-LITE reduces downward heat losses to the
sub-floor ensuring more of the heat is transferred through
the finished floor surface.
1
3
2
4
1. Laminate/Timber Floor
2. Polyester Vapour Barrier
3. ECOFILM Elements
4. ECOMAX-LITE Thermal In
