Floor Construction
Kit Contents
Before laying ECOFILMPRO on either a suspended
wooden floor or concrete sub-floor it is necessary to
install a layer of ECOMAX-LITE thermal insulation.
ECOFILMPRO is a complete heating solution in a box for most
laminate and engineered hardwood floors.
Simply select the floor coverage required from kit sizes
available: 5m2, 10m2, 15m2 & 20m2
This will minimise heat losses and ensure quicker
heat-up times for the floor. It will also act as a means of
sound deadening which is required for laminate floors.
= Roll of 500mm wide ECOFILM
Unroll the ECOFILMPRO and cut to required lengths.
= Heating Element Connection Crimps
Cover the floor area with elements laid in parallel.
Elements should NEVER overlap. Connect the wiring
harness to the heating element with the supplied crimping
tool and insulate the connector with mastic adhesive tape.
= Cold Tail Connection Leads (Brown & Blue)
= Mastic Insulation Tape
= Green Polyester Tape Discs
Cover the total floor including non heated areas with a
layer of Polyester Vapour Barrier (PVB) before laying the
chosen floor covering.
= Ratchet Crimping Tool
= Full Installation Instructions
= 10 Year Guarantee Certificate
1
Product Codes
Product
Code
Description
EPRO-5
5m2 ECOFILMPRO Kit
158.90
EPRO-10
10m2 ECOFILMPRO Kit
258.90
EPRO-15
15m2 ECOFILMPRO Kit
358.90
EPRO-20
20m ECOFILM
458.90
3
2
Price ex VAT
(£)
2
PRO
Kit
4
5
1. Laminate/Timber Floor
2. Polyester Vapour Barrier
3. ECOFILM Heating Elements
4. ECOMAX-LITE Thermal Insulation
Required Accessories
5. Wood/Concrete Sub Floor
Product
Code
Description
Price
ex
VAT
(£)
EL06
ECOMAX-LITE Thermal Insulation
( 800mm x 1250mm x 6mm )
5.50
PVB12
Polyester Vapour Barrier ( 1m x 12m )*
28.00
PVB25
Polyester Vapour Barrier ( 1m x 25m )**
47.00
ET16W
White Touch Screen Thermostat (16A)
85.00
ET16S
Silver Touch Screen Thermostat (16A)
85.00
ET16B
Black Touch Screen Thermostat (16A)
85.00
TH232
Digital Programmable Thermostat (15A)
68.00
TH131
Manual Analogue Thermostat (15A)
50.00
ADT50
Adhesive Tape ( 50mm x 50m )
6.40
For Thermostat
information
see page 20 & 21
There are sufficient accessories in each kit to complete
the product installation in a single regularly shaped room.
If you choose to use a single kit to cover multiple rooms
additional accessories may be required.
Additional Accessories
Price ex VAT
(£)
CRIMP10
10 x Connection Crimps
4.50
CTBL10
Cold Tail Leads ( Blue )
1.5mm2 x 10m
6.50
Cold Tail Leads ( Brown )
1.5mm2 x 10m
6.50
MASTIC1
1000mm x 101mm Mastic Tape
20.00
GTD20
* 1m x 12m of PVB covers
of floor area
** 1m x 25m of PVB covers 22m2 of floor area
Description
CTBR10
10m2
Product
Code
20 x Green Termination Discs
1.20
call our sales team on 01592 760928 or email enquiries@flexel.co.uk
