Size Penetrating of Blank Opening Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
BLANK OPENINGS IN CONCRETE FLOORS / WALLS ( CONTINUED )
Max . area of opening = 240 sq in with max dim of 20 ” Max . 2-1 / 2 ” dia or 2 ” x 2 ” blank opening
NEW Max . 2-1 / 2 ” Blank opening 3 Hr
Concrete Floors / Walls
System Number [ Similar FM Approved System ]
2 Hr ◼ FS-ONE MAX W-J-0015 3 Hr FS-ONE MAX W-J-0022
CP 680 and FS-ONE MAX
NEW Max . 4 ” Blank opening 2 Hr CP 618 FM 593
NEW
Max . 900 sq . in . opening 4 Hr
CFS-COS , CP 619 , and FS-ONE MAX
Penetrating Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
METALLIC PENETRANTS IN CONCRETE FLOORS / WALLS
Max . 12 ” steel , max . 4 ” copper , conduit or EMT pipe ( one or more ) ( 2-1 / 2 ” Concrete ) ( AS varies )
Max . 10 ” steel , cast iron , max . 4 ” copper , conduit or EMT pipe ( AS = 0 ” to 1-1 / 4 ”)
Max . 6 ” steel , cast iron , conduit or max . 4 ” EMT pipe ( AS = 0 ” to 1-3 / 8 ”)
Max . 10 ” steel , max . 4 ” copper , conduit or EMT pipe ( foam as backer ) ( AS = 0 ” to3-1 / 4 ”)
Max . 20 ” steel , cast iron , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( Sleeve Optional ) ( AS = 0 ” to 2-1 / 4 ” for 3 Hr ) ( AS = 0 ” to 12 ” for 2 Hr )
Max . 21 ” steel pipe ( AS = 0 ” to 3 ”)
Max . 10 ” steel or cast iron pipe ( AS = 0 ” to 1-1 / 4 ”)
Max . 10 ” steel , cast iron , max . 4 ” copper , conduit or EMT pipe ( includes Hollow Core ) ( AS = 0 ” to 3-1 / 4 ”)
Max . 30 ” steel , cast iron , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( Sleeve Optional ) ( AS = 0 ” to 1-7 / 8 ”) ( may be installed with continuous POC )
Max . 4 ” steel , conduit , or EMT pipe ( AS = ¾ ”)
Max . 2 ” steel , cast iron , conduit , or EMT pipe ( AS = 0 ” to 1-13 / 16 ”)
Max . 30 ” steel , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( AS = 0 ” to 7 / 8 ”)
Max . 30 ” steel , cast iron , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( 2-1 / 2 ” concrete ) ( AS = 0 ” to 7 / 8 ”)
Max . 1 ” flexible steel conduit ( AS = 1 / 2 ” to 1-1 / 2 ”)
Max . 8 ” aluminum tubing ( sleeve optional ) ( AS = 1 / 2 ” to 1-1 / 2 ”)
Max . 1 ” flexible steel conduit ( 2-1 / 2 ” Concrete ) ( AS = 1 / 2 ” to 1-1 / 4 ”)
Max . 8 ” steel , max . 4 ” copper , conduit or EMT pipe ( AS = 0 ” to 1-7 / 8 ”)
Max . 30 ” steel , cast iron , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( 2-1 / 2 ” Concrete ) ( AS = 0 ” to 1-7 / 8 ”)
Max . 4 ” Copper , steel , cast iron , steel conduit or EMT ( AS = 0 ” to 5-7 / 8 ”)
Max . 4 ” Steel conduit or EMT ( Multiple in max 32 ” x 7 ” opening ) ( AS varies )
Max . 4 ” steel , cast iron , copper , steel conduit or EMT ( Optional sleeve ) ( AS = 0 ” to 5-3 / 8 ”)
FM 336
FM 710
System Number [ Similar FM Approved System ]
3 Hr CP 637 C-AJ-1140
2 Hr ◼ ◼
3 Hr ◼ ◼
FS-ONE MAX CP 606 CFS-S SIL GG CFS-S SIL SL
FS-ONE MAX CP 606 CFS-S SIL GG CFS-S SIL SL
C-AJ-1149
C-AJ-1150
3 Hr ◼ ◼ FS-ONE MAX C-AJ-1154
2 or 3 Hr ◼ ◼ FS-ONE MAX C-AJ-1155
3 Hr ◼ FS-ONE MAX C-AJ-1156
2 Hr ◼ ◼
FS-ONE MAX CP 606 CFS-S SIL GG CFS-S SIL SL
C-AJ-1158
3 Hr FS-ONE MAX C-AJ-1184
3 Hr ◼ FS-ONE MAX C-AJ-1226
3 Hr CP 618 C-AJ-1276
3 Hr CP 618 C-AJ-1277
3 Hr FS-ONE MAX C-AJ-1278
2 Hr FS-ONE MAX C-AJ-1291
2 Hr ◼ FS-ONE MAX C-AJ-1326
2 Hr ◼ ◼ FS-ONE MAX C-AJ-1342
2 Hr FS-ONE MAX C-AJ-1346
3 Hr ◼ CP 606 C-AJ-1372
2 Hr ◼ FS-ONE MAX C-AJ-1380
2 or 3 Hr ◼ Fire Foam C-AJ-1382
2 Hr Fire Foam C-AJ1-388
2 or 3 Hr ◼
FS-ONE MAX CFS-S SIL GG CFS-S SIL SL
C-AJ-1421
