chemical and
petrochemical facility
construction
large diameter
vessel fabrication
tubular
structures
pressure vessel
construction
internal
welds
power plant
construction,
nuclear and
conventional
General
fabrication
wind and wave
farm construction
shipyard
construction work
FOR MORE INFORMATION ABOUT THE SUITABILITY OF FIREFLY FOR YOUR
INTENDED APPLICATION, PLEASE CONTACT US.
SPECIFICATIONS
Minimum Weld Diameter
6 inches (150mm)
Maximum Weld Diameter
Unlimited
Maximum Wall Thickness
Unlimited
Maximum Oscillation Width
3.6 inches (92mm) independently adjustable in 0.0001 inch (0.01 mm)
increments
Dwell Time
0-8 independently adjustable in 0.01s increments
Travel Speed
0-270 inches (0-6858mm) per minute
Wire Capacity
0.8 – 2.0mm
Machine Weight
10kg Wire off board model
14kg Wire on board model (without 5kg spool)
Machine Dimensions
Length 30cm
Width 17cm
Height 27cm to 33cm
WWW.IPWL-WORLDWIDE.COM
7
