Fender® | Fender® Passport®
Passport®
Fender® Passport® PRO
Any time and any place you need big sound with great clarity and convenience, there’s a Fender Passport Pro system that’s
right for you. Pro models are the latest step in the ongoing evolution of Passport into the very finest in portable PA solutions;
keeping the best of previous Passport generations and adding new features and improved functionality so that Passport
systems are ideal for whatever your application may be - education, sporting, and worship events; meetings, seminars and
presentations; gigs at parties, small clubs and coffee houses.
Passport® STUDIO
Fender revolutionizes the recording industry by empowering a new generation of mobile-minded producers and engineers with
the world’s first truly portable world-class studio monitoring system — Passport Studio.
Monitoring consistency is a key factor in producing mixes that translate properly from system to system. With the advent of
powerful portable recording workstations and the increasing convenience of fully “in the box” audio production, the need for
highly portable and accurate studio monitors is now more important than ever. Enter Passport Studio.
Passport Studio houses a world-renowned FOCAL® driver set in a portable, protective and meticulously tuned enclosure,
complemented by convenient front-panel controls and connectivity. Travel from tracking to mixing sessions down the street or
across the globe, with complete confidence that your monitors will arrive unharmed. Fender Passport Studio — “World-class
monitoring made portable” — Powered by FOCAL®.
Passport® MINI
Passport Mini offers convenient amplification for any instrument or microphone. It’s perfect for performances by street
musicians and students, as well as a basic public address system for events and presentations. It goes anywhere thanks to
its dual AC or Battery-powered capabilities. It can even be used as a music media playback system or computer recording
interface.
Passport® 500 PRO
• Output Power: 500 Watts, Class-D Power Amp
• Channels: Eight - (Six Mic/Line, Two Stereo)
• Inputs: Eight - (Six 1/4" / XLR MIc/Line and Two 1/4" / RCA Stereo)
• Controls: Tilt Tone Control on Each Channel, Level, Reverb Send, Master
Volume, Master Tone, 20db Pad
• Effects: Reverb
• Speaker: Two - 10" Fender® Special Design, Two - 1", 6 Ohm Dome Tweeters
• Weight: 44 lbs. (19.96 kg)
• Unique Features: USB port that lets you record your performance with CD
quality (.wav) straight to USB flash drive, six mic lines with XLR and 1/4" inputs,
two stereo inputs with 1/4" and 1/8" (for MP3 player) inputs, 1/4" subwoofer
out with 120Hz high pass filter on speaker out, CD-quality .wav and mp3 file
playback, speaker systems feature tightly controlled coverage to minimize
feedback, 35mm (1-3/8") stand adapters are built In to each speaker cabinet,
mic/cable storage compartment with latching lid, 100V-120V, 220V-240V
Switchable Operation
PART #
DESCRIPTION
0694405060 Passport® 500 PRO, 230V EUR
• Output Power: 300 Watts, Class-D Power Amp
• Channels: Six - (Four Mic/Line, Two Stereo)
• Inputs: Six - (Four 1/4" / XLR Mic/Line and Two 1/4" / RCA Stereo)
• Controls: Tilt Tone Control on Each Channel, Level, Reverb Send, Master
Volume, Master Tone, 20db Pad
• Effects: Reverb
• Speaker: Two - 8" Fender® Special Design, Two - 1.2" Horn-Loaded Tweeter
• Weight: 44 lbs. (19.96 kg)
• Unique Features: 4 mic/line inputs with XLR and 1/4" inputs, 2 stereo channels
with 1/4" and 1/8" (for MP3 player) inputs, phantom power on mic input
channels, LED indicators above each channel input, 1/4" subwoofer output
with 120hz high pass filter on speaker out, preamp out and power amp inserts,
speaker systems feature tightly controlled coverage to minimize feedback,
35mm (1-3/8") stand adapters are built-in to each speaker cabinet, mic/cable
storage compartment with latching lid, 100V-120V, 220V-240V Switchable
Operation
PART #
DESCRIPTION
0694403060 Passport® 300 PRO, 230V EUR
166
For more information go to fender.com
Passport® 300 PRO
Colors and specifications subject to change without notice. For more information go to fender.com
