T he Agricultural Industry Electronics Foundation( AEF) has certified two functionalities of the CLAAS app at the same time – ISOBUS UT and Auxiliary Control. The abbreviation UT stands for Universal Terminal, which means that the app can be used to operate a wide range of ISOBUS implements. This has the great advantage that users only need one terminal for all the different implements. Auxiliary Control, on the other hand, means enhanced user-friendliness and flexibility as the various implement functions can be transferred from the app to the function buttons of any Auxcompatible multifunction control lever. Having obtained certification, the EASY on board app is now listed in the official AEF database. Farmers and contractors can, for example, use this database to check which implements can be controlled with the EASY on board app before making a new investment. How the EASY on board app works
The flexible options offered by a tablet PC, which is already in use on many farms, make the EASY on board app a low-cost alternative to the standard ISOBUS terminal. When it is not being used to control an implement, a tablet can
|
be used all year round for many other agricultural and nonagricultural purposes – from surfing the internet to answering e- mails, navigation to checking the weather forecast. With the EASY on board app, every driver can use his or her personal tablet as a terminal for machine control.
To use the EASY on board app, you need an Apple tablet( iPad Air or newer) with the operating system IOS 9.0 or later. On the machine side, the app assumes that the implement and tractor are connected by an ISOBUS cable and the rear ISOBUS socket. A special WLAN adapter( CWI- CLAAS Wireless Interface) and a universal mount for the tablet are also needed. Both are available from CLAAS dealers.
The WLAN adapter, which is connected to the in-cab ISOBUS socket on the tractor, allows communication between the implement and the tablet; at the same time, the socket and adapter also guarantee a reliable power supply to the tablet.
The EASY on board app is available in the App Store for free download to a tablet. It just has to be installed once and creates the operating display for the implement currently in use on the touchscreen. From this display, the implement can be operated very easily by touching the screen.
|
T hese additional Efficient models are being introduced at the request of operators wanting a high-performance, high-power tractor with a reasonable amount of automation but without the‘ bells and whistles’ features of the top-spec Premium models,” says Ray Spinks, sales director and general manager at AgriArgo UK, the McCormick distributor in Great Britain and Ireland. The Efficient specification was introduced last year on 143-166hp four-cylinder models in the McCormick X7 Series and on a pair of six-cylinder tractors – the 160hp X7.650, which itself was a new addition to the range, and the 165 / 175hp X7.660.
“ The transmission is constantly highlighted by operators as an attractive feature of the McCormick X7 tractors because of its progressive gearing, silky smooth powershifts and effective road and field auto functions”
Now, it is also available on the X7.670, which has 177hp for draft work boosting to 192hp for pto implements and towing trailers, tankers and spreaders, and on the X7.680 with 188hp rising to 212hp.
Standard specification for the new models includes three mechanical spool valves plus one electric valve; 123-litre / min loadsensing hydraulics plus a 44- litre / min pump dedicated to steering and ancillaries; the 24x24- speed Pro Drive transmission; four-speed pto with‘ economy’ as well as‘ power’ gearing; and 9300kg rear lift capacity.
Inside the spacious Premiere cab, which has manual instead of climate control air conditioning, there is a swivelling air suspension driver’ s seat and a‘ hide away’ passenger seat. Outside, 10 work lights illuminate the tractor’ s
|
surroundings. In place of the seat-mounted armrest console found on full-spec Premium versions is a neat layout of main controls to the driver’ s right. On either side of the dials used for setting up and adjusting the electronic rear hitch are levers for the mechanical spool valves, pto speed selection and the optional creep gearbox, which takes the total complement of ratios to 40 forward and reverse.
Ahead of them is the comfortable multi-function joystick, which carries a roller switch for easy linkage lift / lower and buttons for the engine speed memory and manual or auto road / field transmission shifting.
Another two buttons regulate the single electric spool valve fitted; the optional mid-mounted electric valves for operating a 3.5 tonne front linkage or a McCormick MPower loader are handled by a small, fully integrated joystick.
Although the X7.670 and X7.680 use the same 6.7-litre BetaPower engine and cast chassis as other six-cylinder models in the range, these are bigger, beefier tractors.
They have a longer wheelbase( 2820mm versus 2750mm), more weight( 3055kg versus 2920kg before ballast) and the ability to run on taller tyres( 42in versus 38in) – all of which helps exploit the greater power and torque available.
They also have the same highly effective semi-powershift transmission as their Premium counterparts, with its smooth, adjustable power shuttle, fourspeed powershift and electronic manual or auto range shifting.
“ The transmission is constantly highlighted by operators as an attractive feature of the McCormick X7 tractors because of its progressive gearing, silky smooth powershifts and effective road and field auto functions,” says Ray Spinks.
A 50kph option, packaged with hydraulic cab and multi-link front axle suspension can be added to the final specification, together with air trailer braking.
|
