Fall Edition Oct.2013 | Page 15

HD-SDI Camera Selection

GESSXHD-92M20XSDI

High-Definition – Serial Digital Interface image
transmission through coaxial cable.
The HD quality picture is transmitted using an existing
wiring
1/3” 2 Megapixel progressive scan, Exmor CMOS, Powerful 20x optical zoom and 16x digital zoom; H.264
& Dual-stream video encoding, HD-SDI 25/30fps @
1080P resolution, Day/Night(ICR); Auto iris, Auto focus,
AWB, BLC, Up to 24 privacy masking areas.

IP Camera Selection
GESSXHD-613MIP

GESSXHD-713MIP

GESSXHD-720MIP

1/3” 1.3 Megapixel progressive scan Aptina CMOS;
Web viewer, CMS(DSS/PSS) & DMSS, 2.8 mm fixed Lens;
IP66; H.264 & MJPEG dual-stream encoding, Max 15fps
@1.3M (1280×960) & 25/30fps @ 720P (1280×720);
Day/Night(ICR); 2DNR, AWB, AGC, BLC; Multiple network monitoring: Max. IR LEDs length 20m; PoE ONVIF
Ver. 2.0.
Available in White Housing.

1/3” 1.3 Megapixel progressive scan Aptina CMOS;
CMS(DSS/PSS) & DMSS, 3.6mm fixed Lens; IP66;
H.264 & MJPEG dual-stream encoding, Max 15fps @
1.3M(1280×960) & 25/30fps @ 720P(1280×720), Day/
Night(ICR), 2DNR, AWB, AGC, BLC, Multiple network
monitoring: Web viewer; Max. IR LEDs length 20m; PoE
ONVIF Ver. 2.0

1/3”
2Megapixel
progressive
scan
Exmor
CMOS; CMS(DSS/PSS) & DMSS; 6mm fixed lens;
IP66; H.264 & MJPEG dual-stream encoding;
25/30fps@1080P(1920×1080); DWDR, Day/Night(ICR),
2DNR, AWB, AGC, BLC; Multiple network monitoring:
Web viewer; (3.6mm,8mm optional); Max. IR LEDs
Length 20m; PoE

GESSXHD-720MVIP

1/3” 2 Megapixel progressive scan Exmor CMOS;
CMS(DSS/PSS) & DMSS 3.3-12 mm Vari-Focal
lens; IP66; H.264 & MJPEG dual-stream encoding,
25/30fps@1080P(1920×1080), DWDR, Day/Night(ICR),
2DNR, Auto iris, AWB, AGC, BLC Multiple network monitoring: Web viewer; Built-in 2/1 alarm in/out Max. IR
LEDs length 20m Micro SD memory; PoE ONVIF Ver. 2.0

GESSXD-330MVIP

1/2.8” 3 Megapixel progressive scan Exmor CMOS;
CMS(DSS/PSS) & DMSS, 3.3~12mm Vari-Focal lens;
IP66; H.264 & MJPEG dual-stream encoding Max 20fps
@ 3.0M (2048×1536) & 25/30fps @ 1080P(1920×1080),
DWDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC,
BLC, Multiple network monitoring: Web viewer; Builtin 2/1 alarm, in/out, Max. IR LEDs length 20m, Micro SD
memory; IK10, PoE ONVIF Ver. 2.0

GESSXHD92M20XIP

1/3” 2Megapixel progressive scan Exmor CMOS; IP67;
Powerful 20x optical zoom and 16x digital zoom, H.264
& Dual-stream video encoding and JPEG image capture, Max 25/30fps@1080P resolution; Day/Night(ICR),
Auto iris, Auto focus, AWB, BLC, Up to 24 privacy masking areas, Built-in Web server, NVR, CMS(PSS/DSS) &
DMSS, ONVIF Ver. 2.0

The brands mentioned in this catalog are for identification purposes only. All trademarks and registered trademarks are the property of their respective owners.
