PRODUCT FOCUS
HIGH-PERFORMANCE VERSATILE ANALYSIS
ALUMINUM OXIDE
The MultiExact 4100 is a highly adaptable multi-gas analyzer specifically designed to address the needs of industrial and medical gas manufacturers .
It can be fitted with a wide range of sensing technologies – Paramagnetic , Zirconia , Gas Filter Correlation ( GFC ), Infrared , and Aluminum Oxide . These proven , digital sensors not only provide highly accurate measurements but also offer operational flexibility in a range of industries and applications .
Using these sensing technologies , the MultiExact 4100 can provide up to four simultaneous gas stream measurements including : oxygen ( O 2 ) at trace , control , and purity levels , carbon dioxide ( CO 2 ), carbon monoxide ( CO ) at % and trace levels , and trace measurements for nitrous oxide ( N 2 O ), methane ( CH 4 ) and moisture ( H 2 O ).
The non-depleting , high-stability sensors help extend maintenance intervals , while intelligent functionality such as independent auto-calibration helps to deliver operational efficiencies over a long product life .
With built-in support for the AquaXact 1688 moisture sensor , up to 32 relays / alarms , and four analog inputs for integrating information from external sensors – such as temperature , pressure , or concentration information from another gas sensor – the MultiExact 4100 shows how sophisticated modern gas analyzers can be .
Analog and digital communications include the traditional 0-10V DC , 4-20mA , RS232 , and RS485 outputs , while also providing optional advanced digital protocols , including Serial Modbus and PROFIBUS , including Serial Modbus , PROFIBUS , and Ethernet ( Modbus TCP / IP ).
In addition to its considerable monitoring capabilities , the MultiExact 4100 also provides engineer-friendly interaction through a high-brightness color touchscreen display and an intuitive , icon-driven user interface .
The MultiExact 4100 combines all the reliability of Servomex ’ s familiar technology range with the flexibility , ease of use , and range of intelligent digital options that the modern IG and medical gas markets demand .
It also offers compliance with US and European Pharmacopoeia methods for assay of medical oxygen and medical air .
