Make Genie JLG JLG JLG JLG JLG JLG JLG Model Z-135 / 70 E300AJ 340AJ E400AJP 450AJ E450AJ 520AJ 600AJ
Platform
Platform height ( m )
41.15
9.19
10.33
12.19
13.77
13.72
16.00
18.46
Working height ( m )
43.15
11.19
12.33
14.19
15.77
15.72
18.00
20.46
Platform size ( m )
0.76 x 1.83
0.76 x 1.22
0.76 x 1.52
0.76 x 1.52
0.76 x 1.83
0.76 x 1.52
0.76 x 1.83
0.91 x 1.83
Horizontal outreach ( m )
18.03
6.17
6.06
6.83
7.62
7.24
10.00
12.10
Up & Over clearance ( m )
23.01
5.17
6.55
7.30
7.70
7.30
8.09
Platform capacity ( kg )
272
230
230
230
250
230
250
230
Jib - overall length ( m )
6.10
1.22
1.22
1.24
1.24
1.24
1.24
1.83
Jib - range of articulation (°)
110
144 (+ 84 / -60)
139 (+ 79 / -60)
144 (+ 84 / -60)
145 (+ 76 / -69)
144 (+ 84 / -60)
145 (+ 76 / -69)
130 (+ 70 / -60)
Overall width ( m )
2.46
1.22
1.93
1.75
2.35
1.75
2.35
2.49
Tailswing - max . ( m )
0.79 - 4.27
0.05
Stowed height ( m )
3.07
2.01
2.00
2.01
2.27
2.01
2.27
2.57
Engine Vehicle
Stowed length ( m )
12.93
5.54
5.52
6.71
6.58
6.45
7.77
8.82
Overall length ( m )
12.93
Wheel base ( m )
4.11 - 4.72
1.65
1.87
2.01
2.36
2.01
2.36
2.48
Machine weight ( kg )
20366
6900
4450
6350
6495
6670
7985
10660
Axle Oscillation ( m )
0.15
0.1
0.1
0.2
Turning radius outside 2WS ( m )
3.10
3.96
0.61
4.78
3.15
4.78
2.95
Turning radius inside 4WS ( m )
2.29
Make
Deutz
Kubota
Deutz
Deutz
Deutz
Model
TD 2011 L03i
D1105 18.5 kW
2.3 L3 36.4 kW
2.3 L3 36.4 kW
D2011 36.4kW
Distributor
Goscor Access Solutions
Eazi Access Eazi Access Eazi Access Eazi Access Eazi Access Eazi Access Eazi Access
Engine Vehicle Platform
Make
MAGNI
MAGNI
MAGNI
MAGNI
MAGNI
MAGNI
MAGNI
MAGNI
Model
DAB28RT
HAB16RT
HAB18RT
HAB20RT
HAB22RT
HAB24RT
HAB28RT
EAB16RT
Platform height ( m )
Working height ( m )
28100
16070
18040
20090
22210
24300
28100
16070
Platform size ( m )
2440
1830
1830
1830
1830
2440
2440
1830
Horizontal outreach ( m )
Up & Over clearance ( m )
Platform capacity ( kg )
250
250
250
250
250
300
250
250
Jib - overall length ( m )
Jib - range of articulation (°)
Overall width ( m )
2500
2330
2330
2330
2330
2500
2500
2330
Tailswing - max . ( m )
Stowed height ( m )
Stowed length ( m )
Overall length ( m )
12030
5190
5570
6540
7710
10030
12030
5190
Wheel base ( m )
Machine weight ( kg )
18400
7780
7920
8260
9500
17200
18400
7780
Axle Oscillation ( m )
Turning radius outside 2WS ( m )
3220
4490
4490
4490
4490
3220
3220
4490
Turning radius inside 4WS ( m )
Make
Model
Distributor
Magni SA
Magni SA
Magni SA
Magni SA
Magni SA
Magni SA
Magni SA
Magni SA
