Tandem Rollers
Compaction Engine Dimensions
Tandem Rollers
Make Ammann Ammann Ammann Ammann Ammann Ammann Ammann Atlas Weycor Model ARX 12-2 ARX 16-2 ARX 26-2 ARX 40-2 ARX 91 AV 70 X AV 110X AW240 Operating weight ( kg ) 1475 1520 2460 4450 9200 7360 10400 2700
Type
Tandem / articulated
Tandem / articulated
Tandem / articulated
Tandem / articulated
Tandem / articulated
Tandem / articulated
Tandem / articulated
Drum width ( mm ) 820 900 1200 1340 1700 1450 1700 1000 Nominal amplitude 0.5 0.5 0.5 0.6 / 0.4 0.7 / 0.35 0.6 / 0.33 0.7 / 0.35 0.5 Vibration frequency ( Hz ) 60 / 70 60 / 70 58 / 66 41 / 55 42 / 55 43 / 52 45 / 55 53 / 61 Centrifugal force High / low amp ( kN ) 22 / 19 23 / 20 46.5 / 38.8 55 / 53.8 78 / 67 65 / 55 110 / 83 21.5 / 28 Make Kubota Kubota Kubota Kubota Cummins Cummins Cummins Deutz
Model D 1105 D 1105
D1803-M-DI- E3B
Tandem
V2403-M-E3B 4B3.3TAA-60-C BTAA3.3-C80 QSB 3.3-C99 D 2011 L2i
Net power ( kW @ rpm ) 20.4 @ 2400 20.4 @ 2400 24.8 @ 2400 34.1 @ 2400 60 @ 2200 60 @ 2200 74 @ 2200 22.5 Length ( mm ) 2140 2140 2500 2915 4720 4410 4760 2670 Width ( mm ) 865 947 1350 1385 1818 1550 1822 1180 Articulation either side ( degrees ) 30 Distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment Force 8 CC
Compaction Engine
Dimensions
Make Atlas Weycor Atlas Weycor BOMAG BOMAG BOMAG BOMAG BOMAG BOMAG Model AW260 AW300 BW90 AD-5 BW120 AD-5 BW141 AD-50 BW161 AD-50 BW161 ADO-50 BW202 AD-4 Operating weight ( kg ) 2900 3000 1600 2750 6900 10000 9800 11800 Type Tandem Tandem Tandem roller Tandem roller Tandem roller Tandem roller Tandem roller Tandem roller Drum width ( mm ) 1250 1250 900 1200 1500 1680 1680 2135
Nominal amplitude 0.5 0.5 0.50 0.50 0.71 / 0.28 0.87 / 0.44
Vibration frequency ( Hz ) 53 / 61 52 / 58 42 / 63 63 / 67 45 / 55 40 / 55
0.87 / 0.44 front - 1.03 rear
40 / 55 front - 40 rear
Centrifugal force High / low amp ( kN ) 25 / 34 29 / 37 8 / 17 36 / 41 75 / 45 95 / 90 95 / 90 126 / 84 Make Deutz Deutz Kubota Kubota Kubota Deutz Deutz Deutz
Model D 2011 L2i D 2011 L2i D 902 D 1803 V 3307 DI-T BF4M 2012 C BF4M 2012 C
Net power ( kW @ rpm ) 22.5 22.5 15.1 24.6 55.4 103 103 100 Length ( mm ) 2670 2670 2194 2529 4400 4840 4840 4610 Width ( mm ) 1364 1414 956 1272 1664 1836 1836 2295 Articulation either side ( degrees ) 30 30 33 / 8 32 / 10
Distributor Force 8 CC Force 8 CC
Kemach Equipment
Kemach Equipment
Kemach Equipment
Kemach Equipment
Kemach Equipment
0.81 / 0.35
40 / 50
TCD 2012 LO4 2V
Kemach Equipment
Dimensions Engine Compaction
Make |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Model |
CC1250 |
CC1300 |
C1300C |
CC2200HF |
CC3800HF |
CC4200HF |
CC5200HF |
CC6200HF |
Operating weight ( kg ) |
3100 |
3900 |
3900 |
8000 |
10700 |
11350 |
12700 |
13600 |
Type |
Smooth |
Smooth |
Combi |
Smooth |
Smooth |
Smooth |
Smooth |
Smooth |
Drum width ( mm ) |
1250 |
1300 |
1300 |
1500 |
1730 |
1730 |
1950 |
2130 |
Nominal amplitude |
0.5 |
0.5 |
0.5 |
0.7 / 0.3 |
0.7 / 0.3 |
0.8 / 0.3 |
0.8 / 0.3 |
0.8 / 0.3 |
Vibration frequency ( Hz ) |
58 |
52 |
52 |
48 / 67 |
48 / 67 |
51 / 67 |
51 / 67 |
51 / 67 |
Centrifugal force High / low amp ( kN ) |
27 |
33 |
33 |
78 / 67 |
90 / 75 |
139 / 92 |
154 / 101 |
166 / 106 |
Make |
Kubota |
Kubota |
Kubota |
Cummins |
Cummins |
Cummins |
Cummins |
Cummins |
Model |
D1703-M |
V2203-M |
V2203-M |
QSB3.3T3 |
QSB3.3T3 |
QSB4.5T3 |
QSB4.5T3 |
QSB4.5T3 |
Net power ( kW @ rpm ) |
26 / 2800 |
34 ( 45 ) |
34 ( 45 ) |
74 ( 99 ) |
74 ( 99 ) |
93 ( 125 ) |
93 ( 125 ) |
113 ( 152 ) |
Length ( mm ) |
2588 |
2725 |
2725 |
4490 |
4490 |
4990 |
4990 |
4990 |
Width ( mm ) |
1262 |
1450 |
1450 |
1620 |
1940 |
1878 |
2138 |
2319 |
Articulation either side ( degrees ) |
|
|
|
|
|
|
|
|
Distributor |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
