Pad Foot Rollers
Pad Foot Rollers
Make Ammann Ammann Ammann Ammann Ammann Ammann Ammann Model ASC 100 ASC 120 ASC 150 ARS 122 ASC 110 ACE Pro ASC170 ARS200 Operating weight ( kg ) 10120 11430 15500 - 18500 10480 11490 16270 19750
Type
Smooth drum / PD shell
Smooth drum / PD shell
Smooth drum / PD shell
Smooth drum / PD shell
S / D smart compaction
Smooth drum / PD shell
Smooth drum / PD shell
Drum
Drum width ( mm ) 2130 2130 2130 2130 2130 2130 2130
Compaction Engine
Dimensions
Number of pads Pad area ( cm2 ) Nominal amplitude 1.85 / 1.15 1.85 / 1.15 42036 1 . 85 / 0.9 Variable amplitude 2.2 / 1.1 2.0 / 1.0 Vibration frequency ( Hz ) 32 / 35 32 / 35 29 / 35 32 / 35 Variable frequency 28 / 35 Variable frequency
Centrifugal force high / low amp ( kN )
277 / 206 277 / 206 325 / 236 275 / 206 Variable 335 / 260 Variable
Make Cummins Cummins Cummins Cummins Cummins Cummins Deutz Model 4 BTA 3.9 - C116 4 BTA 3.9 - C116 QSB 4.5 - C160 4BTAA3.9C99 QSB 4.5 - C160 QSB 4.5 - C160 TCD 6.1 L6 Net power ( kW @ rpm ) 87 86 @ 2200 119 @ 2200 74 @ 2200 119 @ 2200 119 @ 2200 160 @ 2300 Length ( mm ) 5630 5630 5900 5460 5780 5900 6688 Width ( mm ) 2250 2250 2258 2260 2258 2258 2258 Height ( mm ) 3027 3027 3075 3030 3070 3075 2985 Turning circle radius ( mm ) Distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment
Make |
Bomag |
Bomag |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Dynapac |
Model |
BW 211 PD-40 |
BW 212 PD-40 |
CA15PD |
CA25PD |
CA30PD |
CA35PD |
DRS120PD |
Operating weight ( kg ) |
11350 |
12750 |
7000 |
10500 |
11300 |
12300 |
12800 |
Type |
Single drum |
Single drum |
Pad foot |
Pad foot |
Pad foot |
Pad foot |
Pad foot |
Drum
Drum width ( mm ) 2130 2130 1680 2130 2130 2130 2130
Compaction Engine
Dimensions
Number of pads 150 150 84 130 130 150 130 Pad area ( cm2 ) 137 137 Nominal amplitude 1.7 / 0.86 1.7 / 0.86 1.7 / 0.8 1.8 / 0.9 1.8 / 0.9 1.7 / 0.8 1.8 / 0.9 Vibration frequency ( Hz ) 30 / 36 30 / 36 32 33 33 33 33
Centrifugal force high / low amp ( kN )
275 / 202 275 / 202 114 / 55 250 / 123 250 / 123 250 / 123 250 / 130
Make Deutz Deutz Kubota Cummins Cummins Cummins Dynapac Model BF4M 2012 C BF4M 2012 C V3307 4BT3,9 QSF3,8 QSF3,8 4CylWT Net power ( kW @ rpm ) 98.0 98.0 55 / 2200 74 / 2300 97 / 2500 97 / 2500 79 / 2200 Length ( mm ) 5840 5840 4510 5560 5560 5560 5600 Width ( mm ) 2250 2250 1870 2256 2256 2276 2260 Height ( mm ) 2985 2985 2700 2890 2890 2890 2977 Turning circle radius ( mm ) Not specified Not specified Distributor Kemach Equipment Kemach Equipment Dynapac Dynapac Dynapac Dynapac Dynapac
Make |
Dynapac |
Dynapac |
Dynapac |
Hamm |
Hamm |
Hamm |
Hamm |
Model |
CA300PD |
CA510PD |
CA 610PD |
3410P |
3411P |
3412P |
3414P |
Operating weight ( kg ) |
12500 |
18300 |
20700 |
11015 |
11795 |
12300 |
14340 |
Type |
Pad foot |
Pad foot |
Pad foot |
Pivoted |
Pivoted |
Pivoted |
Pivoted |
Drum
Drum width ( mm ) 2130 2130 2130 2140 2140 2140 2140
Compaction Engine
Dimensions
Number of pads 150 150 150 140 140 140 140 Pad area ( cm2 ) Nominal amplitude 1.7 / 0.8 1.8 / 1.1 1.8 / 1.1 1.61 / 0.68 1.61 / 0.68 1.87 / 0.88 1.90 / 0.90 Vibration frequency ( Hz ) 33 29 / 31 29 / 31 30 / 40 30 / 40 30 / 40 30 / 40
Centrifugal force high / low amp ( kN )
300 / 146 317 / 231 317 / 231 211 / 158 211 / 158 256 / 215 256 / 215
Make Cummins Cummins Cummins Deutz Deutz Deutz Deutz Model 4BTA 6BTA QSB6,7 TCD 2012 L04 TCD 2012 L04 TCD 2012 L04 TCD 2012 L04 Net power ( kW @ rpm ) 82 / 2200 127 / 2200 129 / 2200 100 @ 2300 100 @ 2300 100 @ 2300 100 @ 2300 Length ( mm ) 5550 6180 6180 5695 5695 5750 5705 Width ( mm ) 2384 2400 2400 2250 2140 2140 2250 Height ( mm ) 2990 3000 3000 3040 3040 3010 3010 Turning circle radius ( mm ) 4005 4005 3690 3690 Distributor Dynapac Dynapac Dynapac Wirtgen SA Wirtgen SA Wirtgen SA Wirtgen SA
