Electric Rope Shovel
Electric Rope Shovel
Dimensions
Hoist motor
Swing motor
Crowd motor
Propel motor
Power Requirement Mining Shovel
Number of motors used
Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu
Model P & H 1900XPC P & H 2300XPC P & H 2800XPC P & H 4100 C
Operating mass ( shoes / mm / kg )
42 ’ shoes / 1066 / 378756
48 ” shoes / 1219 / 381931
55 ” shoes / 1397 / 767615
70 ” shoes / 1778 / 769883
56 ” shoes / 1422 / 1079000
72 ” shoes / 1829 / 1084000
76 ” shoes / 1930 / 1243300
87 ” shoes / 2210 / 1247800
P & H 4100C BOSS
130 ” shoes / 3302 / 1424711
138 ” shoes / 3505 / 1410184
P & H 4100XPC
76 ” shoes / 1930 / 1532235
87 ” shoes / 2210 / 1536771
Radius of cut ( m ) 17.8 21.3 24.2 24.7 24.7 23.9 24.0 Width ( overall ) ( m ) 6.71 12.5 13.1 13.1 12.8 14.4 15.0 Ground clearance ( m ) 0.66 0.9 1.0 1.1 1.1 0.7 0.7 Track length on ground ( m ) 7.62 9.9 10.8 11.6 11.6 11.7 11.5 Max speed ( km / hour ) 1.7 1.8 1.8 1.8 1.8 1.8 1.8 Tail swing radius ( m ) 7.0 10.1 9.9 10.2 11.6 9.8 9.9 Height of cut ( m ) 13.0 13.5 16.6 15.8 16.9 16.8 18.9 Dumping height ( open door ) ( m ) 8.2 8.5 9.1 9.1 9.5 9.5 10.8
P & H 4800XPC
100 ” shoes / 2450 / 1661500
Continous rating ( kW @ V ) 328 @ 500 1089 @ 500 2096 @ 690 2388 @ 690 2388 @ 690 2388 @ 690 2388 @ 690 Peak developed power ( kW ) 455 1450 2388 2834 2976 2964 3527 Continous rating ( kW @ V ) 203 @ 500 507 @ 500 1090 @ 690 1090 @ 690 1090 @ 690 1635 @ 690 1635 @ 690 Peak developed power ( kW ) 295 617 1363 1370 1383 1644 1742 Continous rating ( kW @ V ) 128 @ 500 272 @ 500 545 @ 690 545 @ 690 545 @ 690 545 @ 690 632 @ 690 Peak developed power ( kW ) 236 450 695 800 774 759 1111 Continous rating ( kW @ V ) 203 @ 500 328 @ 500 1090 @ 690 1090 @ 690 1090 @ 690 1090 @ 690 1090 @ 690 Peak developed power ( kW ) 352 684 1973 1264 1755 1644 1644
Supply Voltage ( V @ Hz )
3300 / 6600
3300 / 5000 / 6000 / 6600
5000 / 6000 / 6600 5000 / 6000 / 6600
6000 / 6600 / 11000
6000 / 6600 / 7200 / 11000
6000 / 6600 / 7200 / 11000
3 Phase @ 50 3 Phase @ 50 3 Phase @ 50 3 Phase @ 50 3 Phase @ 50 3 Phase @ 50 3 Phase @ 50 Supply Transformer ( kVA ) 1250 ( Minimum ) 2000 ( Minimum ) 2750 ( Minimum ) 3000 ( Minimum ) 3300 ( Minimum ) 3750 ( Minimum ) 3750 ( Minimum )
Minimum short circuit VA available at shovel
13 MVA 16 MVA 22 MVA 25 MVA 25 MVA 30 MVA 30 MVA
Nominal Payload ( mt ) 18 45.4 59.0 81.6 90.7 99.8 - 108.9 122.5
Nominal Dipper Capacity ( cubic m )
10.7
SAE struck 18.3 - 25.5 SAE 2:1 20.2 - 27.8
SAE struck 26.8 - 33.6 SAE 2:1 29.2 - 36.6
Range Dipper Capacity ( cubic m ) 7.5 - 19.1 18.3 - 25.5 26.8 - 33.6
SAE Struck 45.9 SAE 2:1 50.8
SAE Struck 44.3 SAE 2:1 48.4
SAE Struck 52.8 - 61.2 SAE 2:1 58.3 - 67.6
Rated Suspended Load ( mt ) 37.2 90.7 122.5 154.2 161.0 195 209 Hoist Motion 1 2 2 2 2 2 2 Swing Motion 2 2 2 2 2 3 3 Crowd Motion 1 1 1 1 1 1 1 Propel Motion 2 2 2 2 2 2 2
SAE Struck 65.7 - 70.3 SAE 2:1 72.5 - 77.6
South African distributor Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA
