Drills
Blasthole Drills , Rotary Config
Make |
RTDrills |
RTDrills |
RTDrills |
Sunward |
Sunward |
Model |
RTD45 |
RTD55 |
RTD75 |
SWDR152B |
SWDR165B |
Hole depth , first pass ( m ) |
6.1 |
9.14 |
12.2 |
5 |
5 |
Maximum hole depth ( m ) |
36.6 |
63.4 |
73.2 |
30 |
30 |
Hole size ( mm ) |
127 / 165 |
127 / 172 |
229 / 311 |
105 / 165 |
138 / 180 |
Undercarriage ( class ) |
Tripple Grouser |
Reichdrill |
Reichdrill |
|
|
Maximum pulldown ( kN ) |
|
|
|
50 |
50 |
Maximum bit load ( kN ) Operating weight ( kg ) |
22246 |
40823 |
81647 |
24000 |
24500 |
Standard engine ( kW ) |
388 |
403 |
708 |
294 |
343 |
Standard low pressure compressor ( m3 / minute ) |
21.2 - 25.4 |
25.5 - 38.0 |
38.8 - 75.5 |
21.8 |
28.1 |
Distributor |
ELB Equipment |
ELB Equipment |
ELB Equipment |
Azize Equipment |
Azize Equipment |
Blasthole Drills , DTH Config
Make Sunward Sunward Model SWDE138B SWDE165B Hole depth , first pass ( m ) 4 6
Maximum hole depth ( m ) ( Depends on pipe diameter )
28 36
Hole size ( mm ) 76 / 78 102 / 114 Hammer size ( inches ) 4.5 5.6 Undercarriage ( class ) Operating weight ( kg ) 15500 23500 Engine ( kW ) 264 343
High pressure compressor ( m ³ / min )
20.3 38.1 Distributor Azize Equipment Azize Equipment
Other Drills Hydro / Water Rockdrills
Make Model Application Powering system Supply Pressure Distributor
Novatek Mk6 drill and jackleg Hand held drilling or feed mounting Hydropower 16 to 18 Mpa Novatek Drills
Drills
Make Komatsu Komatsu Komatsu Model ZT44 77XR 320XPC
Hole depth , first pass ( m ) 6.1 16.8
Maximum hole depth ( m ) 42.7
85 with 6 pipe rotary carousel
19.8 with optional of 21.3
Hole size ( mm ) 114 - 216 200 - 270 270 - 444 Undercarriage ( class )
B8 excavator-type
Maximum torque ( Nm ) 7500 14900 34040 Maximum bit load ( kg ) 5443 34925 68083 Operating weight ( kg ) 38555 90718 181437
39.4 single pipe rack and 59.4m dual pipe rack
Heavy-duty lug and tumbler drive system
Engine Make ( 1 ) Cummins Cummins ( Electrical ) Engine Model QSK 19 , Tier 2 QST 30 , Tier 2 Standard engine HP Mode ( kW ) 570 783 Standard engine LP Mode ( kW ) 597 Engine make ( 2 ) Engine Model Standard engine HP Mode ( kW ) Standard engine LP Mode ( kW )
Compressor Type Sullair 20 / 12 ( 1150 )
Rotary screw , oil flooded
High pressure mode ( m3 / minute ) 32.9 @ 34.5 @ 1800 56.6 97 Low pressure mode ( m3 / minute ) 38.5 @ 24.2 @ 2100
Electrical System
Spec . Catalog No .
24V
EN-ZT44SPEC01- 0620-V2
Optional 3 phase alternating current 6.3 KV
EN-77XRSPEC01- 0919-V2
Gardner-Denver SSY Series oil-flooded screw type
Full electrical operation @ 50Hz 6.6 to 7.2KV
EN-320XPCSPEC01- 0919-V3
South African distributor Komatsu SA Komatsu SA Komatsu SA
