Medium size wheel Loaders
Loaders
Komatsu“ medium size” wheel loader line-up( 7.5 t TO 24.4 t) Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Model: WA150-6 WA200-6 WA250-6 WA320-6 WA380-6 WA430-6 WA480-6 Engine net power: kW 74 94 103 125 142 172 223( SAE: J1349 / ISO 9249) @ rpm 2000 2000 2000 2000 2100 2100 2000
Bucket: Capacity:( Std SAE Heaped)
Compact Loaders
m ³ 1.4 / G. P. 1.9 / G. P. 2.1 / G. P. 2.6 / G. P. 3.1 / G. P. 3.5 / G. P. 4.3 / G. P.
Bucket Range m ³ 1.2- 1.5 1.7- 2.4 1.9- 2.7 2.1- 3.2 2.7- 4.0 3.1- 4.6 3.8- 6.1 Breakout Force kgf 6780 8465 10830 11700 17300 19800 25400
Static Tipping Load:( Straight)
Static Tipping Load:( Full turn)
Dumping Clearance( max. height at 45 °)
Dimensions: kg 6800 8785 11530 11795 14660 13850 20110
kg 5920 7555 10140 10550 12700 11985 17315
mm 2670 2670 2735 2740 2820 2895 3195
Height( to top of cab) mm 3060 3110 3200 3200 3390 3390 3500 Width( with bucket) mm 2390 2565 2705 2760 2925 3065 3190 Length( Incl. bucket) mm 6365 7010 7135 7660 8310 8460 9325
Operating weight: Includes the following:
Attachments: kg 7780 9630 11245 13705 17510 18170 25090
( m ³)/ Bucket 1.4 / G. P. 1.9 / G. P. 2.1 / G. P. 2.6 / G. P. 3.1 G. P. 3.5 / G. P. 4.3 / G. P. Tyres 17.5 x 25 17.5 x 25 20.5 x 25 20.5 x 25 23.5 x 25 23.5 x 25 26.5 x 25( rating) 12PR L2 12PR L4 12PR L3 12PR L3 20PR L5 20PR L5 20PR L5
Spec. Catalog No. CEN00370-02 CEN00268-03 CEN00259-03 CEN00270-03 CEN00076-06 CEN00139-05 CEN00134-06
Make Manitou Manitou Manitou Manitou
NOTES
Model 1340R 1640R 1800R 3300V NXT2 Wieght( kg) 2200 2792 2892 4123
Dimensions Capacities Engine
Make |
Yanmar |
Yanmar |
Yanmar |
Yanmar |
Model |
4TNV88 |
4TNV98- ZNMS3R1 |
4TNV98- ZNMS3R1 |
4TNV98CT- NMS |
Torque( SAE J1349)( Nm @ rpm) |
142 / 1600 |
241 / 2500 |
241 / 2500 |
294 / 2500 |
Operating load( kg) |
612 |
748 |
817 |
1497 |
Tipping capacity( kg) |
1224 |
1496 |
1633 |
|
Max travelling speed( km / hour) |
10.70 |
12.60 |
12.60 |
13 |
Height( fully raised)( mm) |
2794 |
3876 |
3876 |
4369 |
Overall height to ROPS( mm) |
1826 |
1948 |
1948 |
2083 |
Length( mm) |
2952 |
3101 |
3139 |
3874 |
Wheelbase( mm) |
923 |
988 |
988 |
1257 |
Width( mm) |
1346 |
1582 |
1582 |
1829 |
Ground clearance( mm) |
211 |
160 |
160 |
229 |
