Drills
Blasthole Drills, Rotary Config
Blasthole Drills, DTH Config
Top Hammer Boom Drills
Drills
Loaders Excavators Hydraulic Mining Shovels Skid and Track Steers Electric Rope Shovels Hybrid Shovels ADTs RDTs Graders Dozers Hopper Feeders Mobile Crushers Mobile Elevating Work Platforms Mobile Screens Mobile Conveyors Pad Foot Rollers Smooth Drum Rollers Pneumatic Tyre Rollers Tandem Rollers Pedestrian Rollers Landfill Compactors Single Drum Compactors Siccor Lifts Telehandlers Articulated Boom Lifts Telescopic Boom Lifts Cranes Generators Mobile Compressors Underground Mining Equip. Drills Cold Recyclers Cold Milling Machines Pavers Concrete Excavator Attachments Other Forklifts
Blasthole Drills, Rotary Config
Make Sunward Sunward Sunward Sunward Sunward Sunward Sunward Model SWDE152B SWDE165B SWDE200B SWDE120S SWDE138S SWDE152S SWDE165A Hole depth, first pass( m) 6 x 6 6 x 6 6 x 6 4 x 7 4 x 7 6 x 6 6 x 6 Maximum hole depth( m) 36 36 36 28 28 36 36 Hole size( mm) 138- 165 138- 180 165- 230 90- 138 115- 152 138- 165 138- 180 Undercarriage( class) Maximum pulldown( kN) 45 45 45 30 30 45 45 Maximum bit load( kN) Operating weight( kg) 22500 23500 24000 14500 15500 22500 26000 Standard engine( kW) 264 336 563 228 264 264 97 + 298
Standard low pressure compressor( m3 / minute)
20.5 28.1 34.6 18 20.4 22.5 30.3 Distributor Azize Azize Azize Azize Azize Azize Azize
Blasthole Drills, DTH Config
Make REL REL REL Sandvik Sandvik Sandvik Sandvik Sandvik Model C615 D C625 D C650 D D25KS D245S D45KS D55SP D75KS Hole depth, first pass( m) 4 6 9- 13 8.65 8.65 8.65 / 10.5 16.8 10.7
Maximum hole depth( m)( Depends on pipe diameter)
20 30 36 27 45 63 32 53
Hole size( mm) 102- 152 114- 203 165- 203 127- 172 127- 203 152- 229 172- 254 229- 279 Hammer size( inches) 4- 5 5- 6 6 5 / 6 5 / 6 6 6 / 8 8 Undercarriage( class) Tripple Grouser Tripple Grouser Tripple Grouser S25HD S25HD S30HD 330SL 330EL Operating weight( kg) 33566 33566 47727 55339 61235 Engine( kW) 240 403 403 343- 469 343- 469 354- 567 567- 708 567- 652
High pressure compressor( m ³ / min)
21 25.5 31 25.4- 34.6 25.4- 34.6 25.4- 45.3 38.2- 56.6 38.2- 56.6 Distributor JMH Equipment JMH Equipment JMH Equipment Sandvik Sandvik Sandvik Sandvik Sandvik
Top Hammer Boom Drills
Make Doofor Doofor Doofor FlexiROC FRD FRD FRD PowerROC Model DF540L DF550L DF560L T45 PCR200 HCR1200EDS-III HCRL100-E3 T35
Recommended hole diameter( mm)
Drill Rod diameters( mm)
Hydraulic rock drill
64
Folding Boom 89-127mm / Fixed boom 89- 140mm
Folding Boom T45- T51 / Fixed Boom T51-T60
COP 2560EX / COP 3060EX
76- 102 89- 115 89- 127 64- 115
T38 / T45 T51 T51 T38-T45
Pneumatic HD712- QED HD715- QED Percussion output power( kW) 14 17 20 25 / 30 16 20 26 19
Engine type
Caterpillar turbo charged. diesel. CAT C9.3 / CAT C9. Tier 3 / Stage IIIA
Caterpillar C7
Caterpillar C9
Engine output power( kW @ rpm) 242 168 @ 2200 261 @ 2200 142 Flushing air capacity( m3 / minute) 4000lpm 4000lpm 4000lpm 12 bar 472CFM 7.1 7.8 13.5 9.7 bar
Operators cabin
Certificate
Distributor
Conax Machine Solutions
Conax Machine Solutions
Conax Machine Solutions
Air-conditioned cabin
Operator’ s cabin. ROPS & FOPS
ISO9001 ISO14001
ROPS / FOPS
ISO9001 ISO14001
ROPS / FOPS
ISO9001 ISO14001
CP1840 EX- Pressure 220bar
Cummins turbo charged. Diesel. QSB 6.7. Tier 3 / stage IIIA
Air-conditioned cabin
Operator’ s cabin. ROPS & FOPS
Epiroc SA ELB Equipment ELB Equipment ELB Equipment Epiroc SA
146 EQUIPMENT SPECS HANDBOOK 2025 / 2026 www. equipmentandhire. co. za
