Underground Mining Equipment
Ore Haulers Articulated Dump Trucks( ADTs)
Make GHH GHH GHH Rham Rham Rham Rham Rham Model MK-A20 MK-A35 MK-42 DT10 DT23 DT32 DT32BE DT50
Dimensions Dump body Engine Transmission
Technology
Length( mm) 9417 10720 10535 7798 8514 10280 10280 12664 Height empty( mm) 2574 2894 2727 2000 2105 3300 3300 2893 Turning circle diameter( mm) 8165 9630 9060 7224 8012 8084 8084 10965 Payload( kg) 20 35 42 10000 23000 32000 32000 55000 Heaped capacity( 2:1)( SAE)( m3) 6- 12.5 13- 21 19- 24 3.5 7 17 17 25 Tipping height( mm) 4936 5860 6098 3688 4123 5060 5060 6940
Make Cummins Mercedes Mercedes
Model QSB6.7 OM470 OM473
Maximum torque( Nm @ rpm)
990 Nm @ 1.500 rpm
2100 @ 1.300 rpm
2750 Nm @ 1.300 rpm
DEUTZ / John Deere / Cummins
BF6L914C / 6068FH250 / QSB6.7
DEUTZ / John Deere / Cummins
BF6L914C / 6068FH250 / QSB6.7
DEUTZ / John Deere / Cummins
BF6L914C / 6068FH250 / QSB6.7
Battery pack
400kWh- LiFEPO4
Cummins
13.5l liquid cooled
Type Dana 32000 Dana 6000 Dana 8000 Kessler axles Drive( mechanical / electric) Mechanical Mechanical Mechanical Hydrostatic Hydrostatic Hydrostatic Hydrostatic Hydrostatic Max speed( fwd)( km / h) 29,9 31,2 28,5 10 13,6 13,6 13,6 13,6 PDS ready option option option Yes Yes Yes Yes Yes Remote ready option option option Autonomous ready option option option
Distributor
GHH Mining Machines
GHH Mining Machines
GHH Mining Machines
Rham Equipment
Rham Equipment
Rham Equipment
Rham Equipment
Rham Equipment
Ore Haulers
Shuttle Cars
Make JAE JAE Phillips Global Phillips Global Phillips Global Phillips Global Phillips Global Model JAE20 JAE14 HC12B HC14B HC16B HC20B HC30B Overall length( mm) 9230 8834 9242 9042 9394 9500 9749
Dimensions
Power source
Overall width( mm) 3780 3560 3841 2972 3073 3886 4445
Chassis height no sideboards( mm)
1435 1223 1092 1238 1308 1448 1750
Ground clearance( mm) 330 237 237 295 289 343 443 Conveyor width( mm) 1422 1625 1422 1422 1422 1422 1626 Capacity max( m ³) 20 14 12.8 18.0 24.5 26.4 35.0 Power supply( V ac) 1000 1000 950 / 1140V 950 / 1140V 950 / 1140V 950 / 1140V 950 / 1140V Pump motor 22kW AC 22kW AC 22kW 22kW 22kW 22kW 22kW
Conveyor motor( DC- variable speed)
26kW 30kW 30kW 30kW 30kW
Conveyor motor( ACVFD) 1 x 26kW 1 x 26kW 30kW 30kW 30kW 55kW 55kW Traction motor( DC) 2 x 40 kW 2 x 35 kW 26kW 30kW 30kW 30kW 30kW Traction motor( ACVFD) 2 x 85kW 2 x 85kW 55kW 55kW 55kW or 85kW 85kW 85kW
Traction
Traction drive
Distributor
4x4. 4-wheel steering
2 x speed reducer. propshafts
JA Engineering Works
4x4. 4-wheel steering
2 x speed reducer. Propshafts
JA Engineering Works
DC or ACVFD DC or ACVFD DC or ACVFD DC or ACVFD DC or ACVFD
Saminco Saminco Saminco Saminco Saminco
Phillips Global Phillips Global Phillips Global Phillips Global Phillips Global www. equipmentandhire. co. za
