Utility Vehicles Mobile Cranes
NOTES
Make Bird Bird Fermel
Dimensions Boom
Engine
Model CU6000 Flatbed
Height( mm) 2100 2300 2790 Width over tyres( mm) 2280 2200 1920 Wheelbase( mm) 3150 Turning radius( mm) 4049 4040 3600 Operating weight( kg) 17340 Rated load capacity( kg) 6000 12000 12000 Max lift height( mm) 9603 Max fwd reach( mm) 4000 8000 8320 Load at max height( kg) 7357 Load at max fwd reach( kg) 3500 1120 2594
Make Various Various
Model
T-Mech Mobile Crane
Cummins / Battery Electric avail.
CTAA 8.3-C Power( SAE J1349)( kW @ rpm) 83 131 138 @ 2200 Distributor Bird Machines Bird Machines Fermel
Utility Vehicles
Graders
Make Bird Fermel Fermel Fermel Fermel Model Grader FLP 12T Grader FLP 19T Grader Med 12T Grader Med 17T Grader
Steering Envelope dimensions
Operating weight( kg) |
10000 |
1200 |
|
12000 |
17000 |
Maximum length( mm) |
7700 |
7950 |
9400 |
7860 |
8210 |
Maximum width( mm) |
2220 |
2350 |
2400 |
2300 |
2300 |
Height to top of cab( mm) |
1600 |
1600- 1900 |
2100- 2400 |
1600- 1900 |
2000- 2300 |
Entry & exit angles |
|
30 / 17 |
32 / 21 |
26 / 14 |
35 / 40 |
Beaching Angles |
|
11.5 / 9 |
6 / 7 |
9 |
9 |
Inner turning radius( mm) |
2570 |
2450 |
3500 |
2750 |
3280 |
Outer turning radius( mm) |
6350 |
5550 |
10500 |
5250 |
7050 |
Maximum lift height( mm) 265 300 250 170 250 Maximum cutting depth( mm) 100 300 300 160- 240 300
Blade Drive
Engine
Blade side shift movement( mm) 780 1100 760 1100 Blade rotation( degrees) 40 37 30 30 30 Blade angle adjustment( degrees) 24 30 20 20 20 Drawbar pull( N) 8000 8000 8000 8000
Rear drive tandem total oscillation( degrees)
Front axle( free wheeling) total oscillation( degrees)
7 7 7 7
10 10 10 10
Maximum speed( fwd / rev)( km / hour) 14 24 24 23 23 Speed / high torque( km / hour) 5 5 5 5
Make Various Cat / Battery Electric avail. Cat / Battery Electric avail.
DEUTZ / Battery Electric avail.
Model C7.1 C7 BF6M 1013 / BF6L 914 TCD 914 L6 Emmision compliance Tier IIII Tier III Tier II Tier III Maximum power output( kW @ rpm) 83 129 @ 2200 162 @ 220 126 @ 2300 / 109 @ 2500 109 @ 2500 / 129 @ 2300 Maximum torque( Nm @ rpm) 412 1268 @ 1400 900 @ 1400 697 @ 1400 / 550 @ 1600 550 @ 1600 / 620 @ 1600 Distributor Bird Machines Fermel Fermel Fermel Fermel
DEUTZ
134 EQUIPMENT SPECS HANDBOOK 2025 / 2026 www. equipmentandhire. co. za
