Articulated Boom Lifts
Make
ATN
ATN
ATN
ATN
Genie
Genie
Genie
Genie
Model
Piaf 10RE
Piaf 1100R
Zebra 12
Zebra 16 STAB
Z-33 / 18 DC
Z-34 / 22N DC
Z-34 / 22 DC
Z-45 / 25J DC
Platform height( m)
7.92
8.92
10.2
14.8
10
10.52
10.52
13.94
Working height( m)
9.92
10.92
12.2
16.8
12
12.52
12.52
15.94
Platform size( m)
0.8 x 0.93
0.8 x 0.93
0.8 x 1.45
0.86 x 1.45
0.76 x 1.16
0.76 x 1.42
0.76 x 1.42
0.76 x 1.83
Platform
Horizontal outreach( m)
3.51
3.74
8.5
9.4
5.57
6.78
6.78
7.65
Up & Over clearance( m)
6.55
7.31
4.42
7.8
4.28
4.62
4.57
7.04
Platform capacity( kg)
200
200
230
230
200
227
227
227
Jib- overall length( m)
2
2
1.22
1.22
1.52
Jib- range of articulation(°)
150
150
133
133
139
139
135
Overall width( m)
1
1.04
1.94
2.19
1.5
1.42
1.73
1.79
Tailswing- max.( m)
Stowed height( m)
1.99
2.14
2.11
2.25
1.98
2
2
2
Stowed length( m)
2.78
3.05
6.05
7.7
4.17
4.19
4.08
5.56
Vehicle
Overall length( m) 2.78 3.05 6.05 7.7 4.17 5.72 5.64 5.56 Wheel base( m) 1.2 1.2 2 2.1 1.9 1.88 1.88 2.03
Machine weight( kg)
2850
3280
5150
8050
3665
5171
5179
7394
Axle Oscillation( m) Turning radius outside 2WS( m)
2
2.16
4
4.55
1.9
4.08
4
4.3
Turning radius inside 4WS( m)
Engine
Make ATN ATN Kubota Kubota Genie Genie Genie Genie Model 24V DC 24V DC 48V DC 48V DC 48V DC 48V DC
Distributor
Concord Access Solutions
Concord Access Solutions
Concord Access Solutions
Concord Access Solutions
Concord Access Solutions
Concord Access Solutions
Concord Access Solutions
Concord Access Solutions
