Underground Mining Equipment
Drill Rigs Hydropowered :
NOTES :
Application Dimensions
Powersource
Make Model Face dimensions ( mm ) Drilled hole depth ( mm ) Roof bolting capability
Novatek Raise Miner-twin drill Typ 3000 x 2000 wide 2000 typ Yes Max raise angle 30 Traction system
Rate of penetration -180M parock strength
Monorail mounted
Overall length ( mm ) Upto 5800 Overall width ( mm ) 900 Chassis height ( mm ) - Ground clearance ( mm ) Number of booms -
-
typ1500
Weight ( kg ) 1270,06 Length of wheel base ( mm ) - Turning circle diameter ( mm ) - Make Model -
Electric motor
Power ( kW @ rpm ) 4 @ 1500 Maxspeed ( fwd )( km / h ) Capacity ( l / sec ) -
Boom articulation-angle of boom to footwall
Boom articulationl-angle of boom vertical plane
Boom swing ( deg ) Boom lift ( deg ) Locorig version available - Distributor
250mm / s ( 1km / h ) in raise
-
-
Defined by working area Defined by working area
Novatek Drills
Engine Steering Dimensions Platform
Underground Scalers
Make |
Bird |
Bird |
Fermel |
Fermel |
MineMaster |
Model |
HR |
LP |
Lib Scaler MKII |
Med 4WS Scaler LP |
RS2.0SB |
Platform height ( mm ) |
- |
- |
2650 |
1600 |
4350 |
Working height ( mm ) |
- |
- |
2770 |
1600 |
2000 - 6200 |
Platform size ( mm ) |
- |
- |
- |
- |
900 x 900 |
Horizontal outreach ( mm ) |
- |
- |
- |
- |
1350 |
Platform capacity ( kg ) |
- |
- |
- |
- |
500 |
Jib-overall length ( mm ) |
7850 |
6100 |
8000 |
3000 |
6120 |
Jib-range of articulation ( mm ) |
30 degrees |
30 degrees |
- |
- |
7680 |
Overall width ( mm ) |
2100 |
2000 |
2120 |
2500 |
2250 |
Stowed height ( mm ) |
2300 |
1900 |
2650 |
1700 |
1974 |
Stowed length ( mm ) |
8050 |
7500 |
9400 |
1700 |
10600 |
Overalllength ( mm ) |
8050 |
7500 |
9400 |
7300 |
10600 |
Wheelbase ( mm ) |
- |
- |
TBA |
TBA |
|
Machine weight ( kg ) |
10500 |
10500 |
10500 |
7800 |
20700 |
Axle oscillation degrees |
- |
- |
10 |
TBA |
40 |
Turning radius outside ( mm ) |
6590 |
5174 |
6793 |
1500 |
5900 |
Turning radius inside ( mm ) |
4330 |
2666 |
4339 |
5250 |
3250 |
Make |
Various |
Various |
DEUTZ |
DEUTZ |
DEUTZ |
Model |
- |
- |
BF6L914 Tier II |
BF4L914 II |
TDC2012 L04 |
Electric
Battery Electric No No Available Available
Distributor Bird Machines Bird Machines Fermel Fermel GHH Mining Machines
