Make Genie Genie Genie Genie Genie Genie Genie Genie Model Z-45 / 25J RT Z-45 / 25J XC Z-51 / 30J RT Z-60 / 37 DC Z-60 / 37 FE Z-62 / 40 Z-80 / 60 ZX-135 / 70 Platform height ( m ) 14 14 15,62 18,16 18,16 23,76 23,77 41,15 Working height ( m ) 16 16 17,62 20,16 20,16 18,87 25,77 43,15 Platform size ( m ) 0,76 x 1,83 0,76 x 1,83 0,76 x 1,83 0,91 x 2,44 0,91 x 2,44 0,76 x 1,83 0,76 x 1,83 0,76 x 1,83 Horizontal outreach ( m ) 7,62 7,55 9,25 11,15 11,15 12,47 18,29 18,03 Up & Over clearance ( m ) 7,16 7,22 7,42 7,39 7,39 8,13 8,83 23,01 Platform capacity ( kg ) 227 454 227 227 227 227 227 272 Jib - overall length ( m ) 1,52 1,52 1,52 1,52 1,52 1,83 1,83 1,83 - 6,10 Jib - range of articulation (°) 135 135 135 135 135 135 135 110 Overall width ( m ) 2,29 2,29 2,29 2,49 2,49 2,49 2,49 2,46 Tailswing - max . ( m ) 0 0 0 0,58 - 0,81 0,58 - 0,81 0 1,17 - 2,24 0,79 - 4,27 Stowed height ( m ) 2,11 2,25 2,16 2,54 2,54 2,56 3 97 Stowed length ( m ) 6,83 6,65 7,5 6,3 6,3 7,58 11,27 12,93 Overall length ( m ) 6,83 6,65 7,5 8,15 8,15 9,25 11,27 12,93 Wheel base ( m ) 2,03 2,03 2,03 2,49 2,49 2,51 2,84 4,72 - 5,03 Machine weight ( kg ) 6924 7352 7212 7530 7756 10430 16284 20502 Axle Oscillation ( m ) - - - - - - - - Turning radius outside 2WS ( m ) 4,5 4,5 4,5 5,69 5,69 5,54 7,47 - Turning radius inside 4WS ( m ) - - - 2,36 2,13 3,02 Make DEUTZ DEUTZ DEUTZ Genie Genie Kubota DEUTZ DEUTZ DEUTZ
Model D2011L03i D2.9 D2011L03i 48V DC
Distributor
Goscor Access Solutions
Goscor Access Solutions
Goscor Access Solutions
Goscor Access Solutions
48V DC / Diesel T4F
Goscor Access Solutions
D 2011 L03i TD 2011 L03i TD 2011 L04i
Goscor Access Solutions
Goscor Access Solutions
Goscor Access Solutions
Platform Vehicle
Engine
Make JLG JLG JLG JLG Manitou Manitou Manitou Model 1250AJP 1500AJP
T500J - Trailor Mounted
T350 - Trailor Mounted
120 AETJ-C 150 AETJ-C 170 AETJ-L
Platform height ( m ) 38,30 46,15 15,30 12,50 9.95 13.4 14.9 Working height ( m ) 40,30 48,15 17,30 12,5 11,95 15.4 16.9 Platform size ( m ) 0,91 x 2,44 0,91 x 2,44 0,76 x 1,22 0,76 x 1,22 1,2 x 0,92 1,20 x 0,92 1,2 x 0,922 Horizontal outreach ( m ) 19,25 22,90 9,60 6,15 7 7,81 9,43 Up & Over clearance ( m ) 18,44 18,40 - - - - - Platform capacity ( kg ) 230 270 Unrestricted - 227 Unrestricted - 227 200 230 200 Jib - overall length ( m ) 2,44 2,44 - - - - - Jib - range of articulation (°) 130 (+ 75 / -55 ) 130 (+ 75 / -55 ) - - + 70 / -70 + 70 / -70 66 / 59 Overall width ( m ) 2,49 2,50 1,8 1,50 1,2 1,91 1,75 Tailswing - max . ( m ) 0,91 0,70 - - - - - Stowed height ( m ) 3,05 3,10 2,15 2,00 1,99 2,09 2,04 Stowed length ( m ) 11,46 12,10 8,30 6,60 3,74 4,55 5,12 Overall length ( m ) - - - - 5,48 6,11 6,84 Wheel base ( m ) 3,81 4,60 - - 1,65 2,2 2 Machine weight ( kg ) 21000 26027 2177 1542 6660 6435 6910 Axle Oscillation ( m ) 0,3 0,3 - - - - - Turning radius outside 2WS ( m ) 5,89 9,50 - - 3,34 4,27 4,30 Turning radius inside 4WS ( m ) - - - - 1,55 1,88 2 Make DEUTZ DEUTZ - - - - -
Model TCD 2.9 55.4 kW
TCD 3.6 T4F 74.4 kW
- - - - -
Distributor Eazi Access Eazi Access Eazi Access Eazi Access Manitou SA Manitou SA Manitou SA
