Tandem Rollers
Compaction Engine Dimensions
Tandem Rollers
Make Ammann Ammann Ammann Ammann Ammann Ammann Ammann Ammann Model ARX 12 ARX 16 ARX 20 ARX 23 ARX 26 ARX 36 ARX 40 ARX 45 Operating weight ( kg ) 1475 1460 1570 2250 2460 3740 4125 4650
Type
Tandem / Articulated
Vibratory tandem roller
Vibratory tandem roller
Tandem / Articulated
Tandem / Articulated
Vibratory tandem roller
Vibratory tandem roller
Drum width ( mm ) 820 900 1000 1000 1200 1300 1300 1380
Tandem / Articulated
Nominal amplitude 0.5 0.5 0.5 0.45 0.42 0.36 / 0.55 0.34 / 0.55 0.34 / 0.55 Vibration frequency ( Hz ) 58 / 66 58 / 66 58 / 66 58 / 66 58 / 66 45 / 57 45 / 57 45 / 57 Centrifugal force High / low amp ( kN ) 23 23 24 41 47 50 52 55 Make Kubota Kubota Kubota Kubota Kubota Kubota Kubota Kubota Model D 1105 D 1105 D 1105 D 1803-M-DI D 1803-M-DI V 2403-M V 2403-M V 2403-M Net power ( kW @ rpm ) 20.4 @ 2400 20.4 @ 2400 20.4 @ 2400 30.6 @ 2400 30.6 @ 2400 40.8 @ 2400 40.8 @ 2400 40.8 @ 2400 Length ( mm ) 2327 2327 2327 2506 2506 2971 2971 2971 Width ( mm ) 865 947 1046 1042 1247 1341 1341 1421 Articulation either side ( degrees ) - - - - - - - - Distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment
Compaction Engine
Dimensions
Make Ammann Ammann Ammann Ammann Atlas Weycor Atlas Weycor Atlas Weycor BOMAG Model ARX 91 AV 70 X AV 110X AV 130 X AW240 AW260 AW300 BW90 AD-5 Operating weight ( kg ) 9200 7715 10400 13100 2700 2900 3000 1600
Type
Tandem / Articulated
Tandem / Articulated
Tandem / Articulated
Tandem / Articulated
Tandem Tandem Tandem Tandem roller
Drum width ( mm ) 1700 - 1 818 1450 - 1630 1700 - 1630 2100 - 2260 1000 1250 1250 900 Nominal amplitude 0.7 / 0.35 0.6 / 0.33 0.7 / 0.35 0.8 / 0.4 0.5 0.5 0.5 0.50 Vibration frequency ( Hz ) 42 / 55 48 / 62 45 / 55 42 / 55 53 / 61 53 / 61 52 / 58 42 / 63 Centrifugal force High / low amp ( kN ) 80 / 72 80 / 72 110 / 83 130 / 100 21.5 / 28 25 / 34 29 / 37 8 / 17 Make Cummins Cummins Cummins Cummins DEUTZ DEUTZ DEUTZ Kubota Model 4B3.3TAA-60-C BTAA 3.3-C80 QSB 3.3-C99 QSB 4.5 C130 D 2011 L2i D 2011 L2i D 2011 L2i D 902 Net power ( kW @ rpm ) 60 @ 2200 60 @ 2200 74 @ 2200 97 @ 2300 22.5 22.5 22.5 15.1 Length ( mm ) 4410 4410 4760 4890 2670 2670 2670 2194 Width ( mm ) 1540 1540 1822 2220 1180 1364 1414 956 Articulation either side ( degrees ) - - - - 30 30 30 33 / 8 degrees
Distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment Force 8 CC Force 8 CC Force 8 CC
Kemach Equipment
Compaction Engine
Dimensions
Make BOMAG BOMAG BOMAG BOMAG BOMAG Dynapac Dynapac Dynapac Model BW120 AD-5 BW141 AD-50 BW161 AD-50 BW161 ADO-50 BW202 AD-4 CC950 CC1200 CC1250 Operating weight ( kg ) 2750 6900 10000 9800 11800 1400 2600 3100 Type Tandem roller Tandem roller Tandem roller Tandem roller Tandem roller Smooth Smooth Smooth Drum width ( mm ) 1200 1500 1680 1680 2135 950 1200 1250
Nominal amplitude 0.50 0.71 / 0.28 0.87 / 0.44
Vibration frequency ( Hz ) 63 / 67 45 / 55 40 / 55
0.87 / 0.44 front 1,03 rear
40 / 55 front 40 rear
0.81 / 0.35 0.4 0.5 0.5
40 / 50 70 58 58
Centrifugal force High / low amp ( kN ) 36 / 41 75 / 45 95 / 90 95 / 90 126 / 84 16.7 27 27 Make Kubota Kubota DEUTZ DEUTZ DEUTZ Kubota Kubota Kubota
Model D 1803 V 3307 DI-T BF4M 2012 C BF4M 2012 C
TCD 2012 LO4 2V
D722 D1703-M D1703-M
Net power ( kW @ rpm ) 24.6 55.4 103 103 100 15 / 3600 26 ( 35 ) 26 / 2800 Length ( mm ) 2529 4400 4840 4840 4610 2107 2395 2588 Width ( mm ) 1272 1664 1836 1836 2295 970 1310 1262 Articulation either side ( degrees ) 32 / 10 degrees - - -
Distributor
Kemach Equipment
Kemach Equipment
Kemach Equipment
Kemach Equipment
Kemach Equipment
Dynapac Dynapac Dynapac www . equipmentandhire . co . za
