Screen Engine

Transport dimensions

Screen Engine

Transport dimensions

Make Powerscreen Powerscreen Powerscreen ROCO ROCO Terex Finlay Terex Finlay Terex Finlay Model

Chieftain 2100X Bivitec

Chieftain 2200 Chieftain 2200 1600S X7 595 683 684 Operating mass ( kg ) 35500 36000 39500 30400 37500 19080 25000 33500 Type 2 deck 2 deck 3 deck Scalping screen

Aggregate screen

Double deck vibrating grid

Double deck incline screen

Triple deck incline screen

Top deck ( mm ) 5880 x 1550 6700 x 1550 6700 x 1550 4880 x 1525 6700 x 1525 3350 x 2600 3660 x 1520 4300 x 1700 Middle Deck ( mm )

Bottom deck ( mm ) 5230 x 1550 6100 x 1550 6100 x 1550 4 675 x 1525 6100 x 1525 - 3000 x 1250

4300 x 1700 ( middle and bottom decks )

Production ( t / hour max ) Up to 400 Up to 650 Up to 700 450 450 On request On request On request Make Cat Cat Cat CATERPILLAR CATERPILLAR DEUTZ Cat Cat

Model C4.4 LRC C4.4 C4.4 CAT C4.4 - T3A CAT C4.4 - T3A D9144

C 4.4 Watercooled

Power ( kW @ rpm ) 83 @ 2200 83 @ 2200 97 @ 2200 97kW 97kW 53 83 83 Hopper ( M ³) Height ( mm ) 3570 3580 3580 3430 3400 3200 3250 3500 Length ( mm ) 18700 19800 19800 15005 18850 9720 15000 17600 Width ( mm ) 2980 3000 3000 2920 3000 2620 3000 3000

C 4.4 Watercooled

Distributor ELB Equipment ELB Equipment ELB Equipment Egelquip Egelquip Bell Equipment Bell Equipment Bell Equipment

Screen Engine

Transport dimensions

Make Terex Finlay Terex Finlay Terex Finlay Terex Finlay Terex Finlay Terex Finlay Terex Finlay Model 693 + 694 + 863 873 883 + 893 984 Operating mass ( kg ) 33500 39250 18300 26300 31000 4800 43100

Type

Double deck incline screen

Triple deck incline screen

Double deck heavy duty scalping screen

Double deck heavy duty scalping screen

Double deck heavy duty scalping screen

Double deck heavy duty scalping screen

Triple shaft horizontal screen

Top deck ( mm ) 6100 x 1520 6100 x 1520 2760 x 1220 3660 x 1520 4800 x 1520 6100 x 1830 6100 x 1930 Middle Deck ( mm )

Bottom deck ( mm ) 6100 x 1520

6100 x 1520 ( middle and bottom decks )

2760 x 1220 3660 x 1520 4800 x 1520 5500 x 1830

6100 x 1930 ( middle and bottom decks )

Production ( t / hour max ) On request On request On request On request On request On request On request Make Cat Cat DEUTZ Cat Cat Cat Cat Model C 4.4 Watercooled C 4.4 Watercooled DT2011 C 4.4 Watercooled C 4.4 Watercooled C 7.1 Watercooled C 7.1 Watercooled Power ( kW @ rpm ) 83 97 49 83 83 151 151 Hopper ( M ³) Height ( mm ) 3580 3580 3100 3400 3400 3600 3500 Length ( mm ) 19360 19360 9600 13700 14800 17900 18900 Width ( mm ) 3000 3000 2550 3000 3000 3000 3000 Distributor Bell Equipment Bell Equipment Bell Equipment Bell Equipment Bell Equipment Bell Equipment Bell Equipment
