Hybrid Shovel
Smooth Drum Rollers Pneumatic Tyre Rollers Tandem Rollers Landfill Compactors Single Drum Compactors Pedestrian Rollers Telehandlers Articulated Boom Lifts Telescopic Boom Lifts Cranes Generators Mobile Compressors Underground Mining Equip . Drills Cold Recyclers Milling Machines Pavers Concrete Mixers Excavator Attachments Forklifts
Hybrid Shovel
Dimensions Engine2 Engine1
Mining Shovel
Make Model
Komatsu
P & H2650CX Operating mass ( kg ) 817889
Std bucket capacity ( SAE heaped ) ( m 3 )
31,1
Standard track pads ( mm ) 1626 Ground Bearing pressure ( N / cm 2 ) 29.6 Max dig reach ( m ) 17.84 Rated suspended load ( mt ) 127.5 Max reach at ground level ( m ) 14.64 Max dump height ( m ) 11.54 Height of cut ( m ) 18.11 Make
MTU Detroit diesel engine Model 2 x 12V Series 4000 Net power ( kW @ rpm ) 2386 @ 1800 Make Model
Cummins diesel engine
2 x QSK50 Net power ( kW @ rpm ) 2386 @ 1800
Counter weight to boom point length ( m )
19.0
Width ( overall ) ( m ) 14.13 Ground clearance ( m ) 2.38 Track length on ground ( m ) 9.89 Max speed ( km / hour ) 1st stage 0.92 Max speed ( km / hour ) 2nd stage 1.99 Tail swing radius ( m ) 8.4
Propel system
Hydraulic motors 2 axial piston variable motor ( perside )
Maximum tractive force ( kN ) 27270
Swing system
Crowd System
Swing motors Swing drives Brakes Max swing speed Slewring gear
Crowd motors
4 x P & HSR motors @ 200HP each 4 x stage planetary transmission Spring loaded / hydraulically released 3.12rpm Sealed triple roller seing ring , internal teeth
2 x P & HSR motors @ 400HP each
Hoist system
Hoist motors
2 x P & HSR motors @ 1250HP each
Electrical system
Fluid
Capacities
System voltage Batteries in series , parallel Working spotlights Service lights
24V 6 x 12V , 6 x 210Ah 22 x high brightness LED lights 16 x LED lights APU unit ( optional ) 24 VDC system ( 260A ) FuelTank Hydraulic oil tank Engine Oil RH pump drive transmission LH pump drivet ransmission Propel gear case Swing gear case Crowd gear case Hoist Gear case RH / LH engine high temp coolant RH / LH engine low temp coolant Spec . Catalog No . South African distributor
8574L 2082L 2 x 190L 63L 58L 2 x 227L 4 x 76L 530L 515L 1317L 639L EN-2650 CXHS01-0420-V4 Komatsu SA
