Excavators
Loaders Hybrid Electric Loaders Excavators Electric Rope Shovels Hybrid Shovels Backhoe Loaders Skid Steers Hydraulic Mining Shovels ADTs RDTs Graders Dozers Hopper Feeders Mobile Crushers Mobile Screens Mobile Conveyors Pad Foot Rollers Smooth Drum Rollers Pneumatic Tyre Rollers Tandem Rollers Landfill Compactors Single Drum Compactors Pedestrian Rollers Telehandlers Articulated Boom Lifts Telescopic Boom Lifts Cranes Generators Mobile Compressors Underground Mining Equip . Drills Cold Recyclers Milling Machines Pavers Concrete Mixers Excavator Attachments Forklifts
Excavators
Backhoe Engine Dimensions Backhoe Engine Dimensions Backhoe Engine
Dimensions
Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Model PC70-8 PC88MR-8 PC130-8 PC138US-8 PC210-10M0 PC228US-8 PC270-8 PC300-8 Operating mass ( kg ) 6590 8225 12380 13480 21300 21900 27140 31100 Std bucket capacity ( SAE heaped ) ( m3 ) 0,3 0,28 0,4 0,5 1.2 0,8 1,35 1,5 Reach at ground level ( mm ) 6220 6725 8170 8180 8670 9700 9450 9910 Max digging depth ( mm ) 4100 4160 5520 5480 5230 6620 5940 6400 Max dumping height ( mm ) 5015 4515 6210 6840 6760 7825 6720 6520
Bucket breakout ( curling ) force ( SAE rated ) ( kN )
54,8 61,3 80,9 93,2 157 149 176 228
Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Model SAA4D95LE-5 SAA4D95LE-5 SAA4D95LE-5 SAA4D95LE-5 SAA6D107E-1 SAA6D107E-1 SAA6D107E-1 SAA6D114E-3 Net power ( kW @ rpm ) ( SAE J1349 ) 48,5 @ 1950 49,0 @ 1950 68 @ 2200 68,4 @ 2200 123 @ 2000 110 @ 2000 140 @ 2050 184 @ 1950 Length ( transport position ) ( mm ) 6080 6175 7590 7260 9630 8700 9940 11300 Width ( overall ) ( mm ) 2260 2330 2490 2490 2800 2800 3190 3190 Ground clearance ( mm ) 350 360 400 395 440 440 498 500 Track length on ground ( mm ) 2765 2235 2880 2880 3275 3275 3700 3700 Max speed ( km / hour ) 4,5 5,1 5,5 5,1 5,5 5,5 5,5 5,5 Tail swing radius ( mm ) 1750 1335 2190 1480 2900 1680 2940 3405 Distributor Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA
Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Model PC350LC-8M0 PC400-8 PC450LC-8 PC500LC-10R PC600-8R1
PC700LC- 8R ( SE )
PC850-8R1
Operating mass ( kg ) 33660 41700 44400 49400 59200 67000 78600 252000 Std bucket capacity ( SAE heaped ) ( m 3 ) 1,9 1,9 2,1 2,1 3,5 4 4,5 15 Reach at ground level ( mm ) 9860 10855 11800 11985 11300 11295 11945 15600 Max digging depth ( mm ) 6310 6845 7790 7695 7060 6910 7130 7900 Max dumping height ( mm ) 6595 7070 7625 7650 7210 7360 7525 9000
Bucket breakout ( curling ) force ( SAE rated ) ( kN )
228 241 243 267 289 289 428 890 Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu
PC3000-6 BH
Model SAA6D114E-3 SAA6D125E-5 SAA6D125E-5 SAA6D125E-5 SAA6D140E-5 SA6D140E-5 SAA6D140E-5 SAA12V159 Net power ( kW @ rpm ) ( SAE J1349 ) 187 @ 1950 257 @ 1900 257 @ 1900 269 @ 1900 320 @ 1800 320 @ 1800 363 @ 1800 940 @ 1800 Length ( transport position ) ( mm ) 10710 11905 12040 12260 11980 11990 13130 - Width ( overall ) ( mm ) 3190 3430 3430 3580 3900 4290 4110 7080 Ground clearance ( mm ) 500 555 550 1385 780 830 840 935 Track length on ground ( mm ) 4030 4020 4350 4350 4250 4500 4500 6000 Max speed ( km / hour ) 5,5 5,5 5,5 5,5 4,9 4,6 4,2 2,4 Tail swing radius ( mm ) 3405 3645 3645 3765 3950 3950 4400 6480 Distributor Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA
Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Liebherr Liebherr Model
PC5500-6 BH
PC4000- 11 ( BH )
PC4000- 11 ( Shovel )
PC7000-11 ( Shovel )
PC7000- 11 ( BH )
PC8000-6 FS R920 R924
Operating mass ( kg ) 538000 404000 398000 673000 682000 752000 21000-21500 24550-25000 Std bucket capacity ( SAE heaped ) ( m 3 ) 29 22 22 36 36 42 0,60-1,25 0,80-1,65 Reach at ground level ( mm ) 19050 16650 5700 17620 20530 3000 9800 10100 Max digging depth ( mm ) 8720 8000 2900 2970 8340 3000 6650 6950 Max dumping height ( mm ) 9730 9700 12000 13760 10860 13900 6750 6950
Bucket breakout ( curling ) force ( SAE rated ) ( kN )
1516 1239 1349 2086 1692 2331 157 171
Make Komatsu Komatsu Komatsu Komatsu Komatsu Komatsu Cummins Cummins Model SSA12V159-2 SDA16V160E-2 SDA16V160E-2 SSDA16V159E-2 SSDA16V159E-2 SDA16V160-2 QSB 6,6 QSB 6,7 Net power ( kW @ rpm ) ( SAE J1349 ) 2 x 940 @ 1800 1400 @ 1875 1400 @ 1875 2 x 1250 @ 1800 2 X 1250 @ 1800 1500 x 2 @ 1800 110kW @ 1800 125kW @ 1800 Length ( transport position ) ( mm ) - - - - - - 9750 9950 Width ( overall ) ( mm ) 7900 8700 8700 6920 6920 9850 2990 3180 Ground clearance ( mm ) 995 930 930 1065 1065 1065 465 465 Track length on ground ( mm ) 7242 8842 8842 10510 10510 8100 3355 3640 Max speed ( km / hour ) 2,2 2,1 2,1 2,5 2,5 2,4 5 5 Tail swing radius ( mm ) 7550 6500 6500 7850 7850 8710 2820 2820
Distributor Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA Komatsu SA
Kemach Equipment
Kemach Equipment www . equipmentandhire . co . za
EQUIPMENT SPECS HANDBOOK 2022 / 2023
21
