Bucket Engine

Dimensions

Make Volvo Volvo Volvo Volvo Volvo Volvo Volvo Volvo Model L90F L90Gz L110F L120F L120Gz L150H L180H L220H

Static tipping load straight ( kg ) 11210 11990 13120 14240 14030 18100 21540 23900 Std operating weight ( kg ) 14980 14580 18300 19200 18010 24090 27020 31190 Std bucket capacity ( SAE ) heaped ( m ³) 2.5 2.6 3 3.3 3.3 4 4.4 5 Bucket breakout force ( kN / kgf ) 118.5 159.3 156.7 164 204,3 202 235.9 244.5 Make Volvo Volvo Volvo Volvo Volvo Volvo Volvo Volvo Model D6E LAE 3 D6E LAE 3 D7E LB E3 D7E LA E3 D7E LA E3 D13F D13F D13F Net power ( kW @ rpm ) ( SAE J1349 ) 128 @ 1700 128 @ 1700 169 @ 1700 179 @ 1700 179 @ 1700 220 @ 1300 245 @ 1400 273 @ 1400 Max travel speed ( fwd / rev ) ( km / hour ) 46.2 44 37 37 40 38 38 36.5 Length ( including bucket ) ( mm ) 7510 7750 8070 8020 8330 8790 9000 9350 Wheelbase ( mm ) 3000 3050 3200 3200 3200 3550 3550 3700 Height to top of cab ( mm ) 3280 3279 3360 3370 3368 3580 3580 3730

Turning circle diameter outside bucket corner ( mm )

11840 12080 12680 12780 13360 14750 14850 15610 Distributor Babcock Babcock Babcock Babcock Babcock Babcock Babcock Babcock

Bucket Engine

Dimensions

Model L350H 5035 5055 5075 5095 8155 LW300FN ZL50GN

Static tipping load straight ( kg ) 38830 1140 1980 3400 3800 6100 3000 5000 Std operating weight ( kg ) 50930 1920 3600 4400 5100 9850 10000 17500 Std bucket capacity ( SAE ) heaped ( m ³) 6,8 0.35 0.55 0.75 0.95 1.55 1.8 3 Bucket breakout force ( kN / kgf ) 450 12.2 32.5 42.9 44.4 65 120 170 Make Volvo Yanmar Yanmar Kohler Kohler DEUTZ Yuchai Weichai Model D16E 3TNV82A 4TNV88 KDI2504 KDI2504 TCD 3.6 L4 YC6B125-T21 WD10G220E23 Net power ( kW @ rpm ) ( SAE J1349 ) 394 @ 1700 18.5 35 55.4 55.4 100 92 @ 2300 162 @ 2000 Max travel speed ( fwd / rev ) ( km / hour ) 35.7 20 20 20 20 20 35 38 Length ( including bucket ) ( mm ) 11160 4050 4950 5120 5270 6450 7050 8165 Wheelbase ( mm ) 4300 1525 1850 2020 2020 2620 2600 3300 Height to top of cab ( mm ) 4170 2170 2380 2450 2480 3010 3025 3485

Turning circle diameter outside bucket corner ( mm )

Distributor

18370 1950 3550 2840 2840 3865 6060 7300

Babcock

Wacker Neuson

Wacker Neuson

Wacker Neuson

Wacker Neuson

Wacker Neuson

XCMG SA XCMG SA

Bucket Engine

Dimensions

Make XCMG XCMG XCMG XCMG XCMG Model LW600K LW700K LW800K LW900K LW1200

Static tipping load straight ( kg ) 6000 7000 8000 9000 12000 Std operating weight ( kg ) 20000 23500 28500 30040 51000 Std bucket capacity ( SAE ) heaped ( m ³) 3.5 4.2 4.5 5 6.5 Bucket breakout force ( kN / kgf ) 201 200 260 260 394 Make Shangchai Cummins Cummins Cummins Cummins Model SC11CB240.1G2B1 QSM11-C290 QSM11 QSM11 QSK19 Net power ( kW @ rpm ) ( SAE J1349 ) 175 @ 2200 216 @ 2100 250 @ 2100 250 @ 2100 418 @ 2000 Max travel speed ( fwd / rev ) ( km / hour ) 36 38 35.5 35.5 33 Length ( including bucket ) ( mm ) 8695 8900 9300 9400 12337 Wheelbase ( mm ) 3400 3450 3600 3600 4500 Height to top of cab ( mm ) 3543 3600 3770 3770 4319

Turning circle diameter outside bucket corner ( mm )

7178 7399 7764 7400 7622 Distributor XCMG SA XCMG SA XCMG SA XCMG SA XCMG SA
