Excavator Attachments
Loaders Hybrid Electric Loaders
Hydraulic Breakers and Rippers
Excavators Electric Rope Shovels Hybrid Shovels Backhoe Loaders Skid Steers Hydraulic Mining Shovels ADTs RDTs Graders Dozers Hopper Feeders Mobile Crushers Mobile Screens Mobile Conveyors Pad Foot Rollers Smooth Drum Rollers Pneumatic Tyre Rollers Tandem Rollers Landfill Compactors Single Drum Compactors Pedestrian Rollers Telehandlers Articulated Boom Lifts Telescopic Boom Lifts Cranes Generators Mobile Compressors Underground Mining Equip . Drills Cold Recyclers Milling Machines Pavers Concrete Mixers Excavator Attachments Forklifts
Make |
Xcentric Ripper |
Xcentric Ripper |
Xcentric Ripper |
Xcentric Ripper |
Xcentric Ripper |
Xcentric Ripper |
Model |
XR22 |
XR32 |
XR42 |
XR52 |
XR82 |
XR122 |
Carrier Weight ( t ) |
18 - 23 |
24 - 32 |
32 - 40 |
40 - 55 |
70 - 90 |
100 - 140 |
Weight with top bracket and tool ( kg ) |
2500 |
3700 |
4200 |
4900 |
10000 |
15000 |
Moil diameter ( mm ) |
- |
- |
- |
- |
- |
- |
Working Length ( mm ) |
1000 |
1160 |
1215 |
1315 |
1530 |
1780 |
Input Power ( kW ) |
- |
- |
- |
- |
- |
- |
Frequency ( blows / min ) |
900 |
1100 |
1100 |
1100 |
700 |
600 |
Length with tool , without top bracket ( mm ) |
2243 |
2715 |
2865 |
3000 |
3575 |
4150 |
Oil flow ( l / min ) |
160 |
190 |
210 |
270 |
420 |
500 |
Working pressure of the hammer ( bar ) |
16MPa |
24MPa |
24MPa |
28MPa |
30MPa |
30MPa |
Acceptable back pressure ( bar )/ return line pressure |
1MPa |
1MPa |
1MPa |
1MPa |
1MPa |
1MPa |
Distributor |
Xcentric Ripper SA |
Xcentric Ripper SA |
Xcentric Ripper SA |
Xcentric Ripper SA |
Xcentric Ripper SA |
Xcentric Ripper SA |
Bucket Crushers
Make ALLU ALLU HARTL HARTL HARTL HARTL Xcentric Xcentric Model D - Series M - Series HBC 650 HBC 750 HBC 950 HBC 1250 XC8 XC8 TH Recommended for excavators weighing ( t ) 10 - 45 50 - 160 ≥ 10 ≥ 18 ≥ 24 ≥ 35 8 - 11 ( Telehandler ) Weight ( without top plate ) kg 960 - 4140 7000 - 29700 - - - - 1200 1320 Operating pressure Mpa - - - - - - 25 25 Operating flow l / min 70 - 400 - - - - - 80 80 Hydraulic circuit - - - - - - Shear mode Shear mode Loading capacity m ³ 0.5 - 4.3 3.8 - 8.5 0.51 0.73 1 1.66 0.35 0.5 Hourly production ( m ³) 36-162 228-372 1700 2800 3950 5720 - - External width ( mm ) - - 600 750 950 1250 850 1100 Internal width ( mm ) - - - - - - 660 660 Length ( mm ) - - 500 500 525 570 1670 1880 Height ( mm ) - - - - - - 880 880
Crushing size ( mm ) 40 - 80 40 - 80 10-100 12-100 12-120 12-120
Jaw opening ( mm ) Rotor Crusher Rotor Crusher - - - -
Distributor Egelquip Egelquip
Machinery Contractors
Machinery Contractors
Machinery Contractors
Machinery Contractors
0 - 16 to 0 - 200
( Crushing cam ) h 260
Xcentric Ripper
0 - 16 to 0 - 200
( Crushing cam ) h 260
Xcentric Ripper
Make Xcentric Xcentric Xcentric Xcentric Xcentric Xcentric Xcentric Model XC9 XC13 XC19 XC21 XC24 XC29 XC34 Recommended for excavators weighing ( t ) 10 - 13 13 - 16 16 - 21 20 - 25 24 - 33 28 - 38 38 - 50 Weight ( without top plate ) kg 1610 1800 2200 2700 3700 4750 5500 Operating pressure Mpa 25 25 25 25 25 25 25 Operating flow l / min 95 120 160 160 180 200 230 Hydraulic circuit Shear mode Shear mode Shear mode Shear mode Shear mode Shear mode Shear mode Loading capacity m ³ 0.35 0.42 0.5 0.7 1 1.2 1.5 Hourly production ( m ³) - - - - - - - External width ( mm ) 930 930 1100 930 1075 1280 1300 Internal width ( mm ) 730 730 900 730 900 1100 1100 Length ( mm ) 1700 1940 1940 2480 2480 2620 2800 Height ( mm ) 890 1000 1000 1250 1250 1250 1320 Crushing size ( mm ) 0 - 16 to 0 - 200 0 - 16 to 0 - 200 0 - 16 to 0 - 200 0 - 16 to 0 - 250 0 - 16 to 0 - 250 0 - 16 to 0 - 250 0 - 16 to 0 - 250
Jaw opening ( mm )
( Crushing cam ) h 370
( Crushing cam ) h 370
( Crushing cam ) h 371
( Crushing cam ) h 372
( Crushing cam ) h 373
( Crushing cam ) h 440
( Crushing cam ) h 440
Distributor Xcentric Ripper Xcentric Ripper Xcentric Ripper Xcentric Ripper Xcentric Ripper Xcentric Ripper Xcentric Ripper
114 EQUIPMENT SPECS HANDBOOK 2022 / 2023 www . equipmentandhire . co . za
