Steering Envelope dimensions
Make Bird Fermel FLP Fermel FLP Fermel Med Fermel Med Model Grader 12T Grader 19T Grader 12T Grader 17T Grader Operating weight ( kg ) 10000 1200 - 12000 17000 Maximum length ( mm ) 7700 7950 9400 7860 8210 Maximum width ( mm ) 2220 2350 ( excluding blade ) 2400 ( excluding blade ) 2300 2300 Height to top of cab ( mm ) 1600 1600 - 1900 2100 - 2400 1600 - 1900 2000 - 2300 Entry & exit angles - 30 / 17 32 / 21 26 / 14 35 / 40 Beaching Angles - 11.5 / 9 6 / 7 9 9 Inner turning radius ( mm ) 2570 2450 3500 2750 3280 Outer turning radius ( mm ) 6350 5550 10500 5250 7050 Maximum lift height ( mm ) 265 300 250 170 250 Maximum cutting depth ( mm ) 100 300 300 160-240 300 Blade side shift movement ( mm ) - 780 1100 760 1100 Blade rotation ( degrees ) 40 37 30 30 30 Blade angle adjustment ( degrees ) 24 30 20 20 20 Drawbar pull ( N ) - 8000 8000 8000 8000
Rear drive tandem total oscillation ( degrees )
Front axle ( free wheeling ) total oscillation ( degrees )
- 7 7 7 7
- 10 10 10 10
Maximum speed ( fwd / rev ) ( km / hour ) 14 24 24 23 23 Speed / high torque ( km / hour ) - 5 5 5 5 Make Various CAT / Battery Electric avail . CAT / Battery Electric avail . DEUTZ / Battery Electric avail . DEUTZ Model - C7 BF6M 1013 / BF6L 914 TCD 914 L6 Emmision compliance - Tier II Tier III Tier II Tier III Maximum power output ( kW @ rpm ) 83 129 @ 2200 162 @ 220 126 @ 2300 / 109 @ 2500 109 @ 2500 / 129 @ 2300 Maximum torque ( Nm @ rpm ) 412 1268 @ 1400 900 @ 1400 697 @ 1400 / 550 @ 1600 550 @ 1600 / 620 @ 1600 Distributor Bird Machines Fermel Fermel Fermel Fermel
Cassette Carriers :
Platform Dimensions Steering
Engine
Make Fermel Lib Fermel Lib Fermel Med SMT Scharf SMT Scharf UVB Model Placer Dumper Roll on Roll off
Evo ’ 20 Cassette Carrier
Cassettemaster - D Cassettemaster - EB MV-U60D-CC
Platform height ( mm ) 2050 2100 1550 - - 3000 Working height ( mm ) - - - - - 3000 Platform size ( mm ) - - - - - 1000 x 1000 Horizontal outreach ( mm ) TBA TBA TBA - - - Platform capacity ( kg ) 5000 8000 5000 - - 1500 Jib - overall length ( mm ) - 8190 6800 - - - Jib - range of articulation ( mm ) - TBA TBA - - - Overall width ( mm ) 2200 1950 2600 2365 2365 3030 Stowed height ( mm ) 2050 TBA TBA 8990 8990 1400 Stowed length ( mm ) 7250 TBA TBA 2400 2400 6405 Overall length ( mm ) 7250 8000 6800 347 347 6405 Wheel base ( mm ) 4150 TBA TBA 3215 3215 Machine weight ( kg ) 12000 TBA TBA 14580 14580 13500 Axle oscillation TBA TBA TBA 7 ° 7 ° Trunion bearing Turning radius outside ( mm ) 7070 6600 7850 4523 4523 6558 Turning radius inside ( mm ) 4670 4320 5200 7165 7165 3515
Make
DEUTZ / Battery Electric avail .
DEUTZ / Battery Electric avail .
DEUTZ / Battery Electric avail .
Cummins Battery Electric DEUTZ Model BF6L 914 BF6L 914 D 914 L06 QSB4.5 - BF6L914 Distributor Fermel Fermel Fermel SMT Scharf Africa SMT Scharf Africa
