Pad Foot Rollers |
Pad Foot Rollers
Make Ammann Ammann Ammann Ammann Ammann Ammann Ammann Model ASC 100 ASC 120 ASC 150 ASC170 ASC200 ASC 250 ASC 110 ACE Pro Operating weight ( kg ) 10120 11430 15500 - 18500 16270 21000 - 26000 25500 11490
Type
Smooth Drum / PD shell
Smooth Drum / PD shell
Smooth Drum / PD shell
Smooth Drum / PD shell
Smooth Drum / PD shell
Smooth Drum / PD shell
S / D smart compaction
Drum
Drum width ( mm ) 2130 2130 2130 2130 2240 2240 2130
Compaction Engine
Dimensions
Number of pads - - - - - - - Pad area ( cm2 ) - - - - - - - Nominal amplitude 1,85 / 1,15 1,85 / 1,15 42036 2,2 / 1,1 - 2,2 / 1,1 Variable amplitude Vibration frequency ( Hz ) 32 / 35 32 / 35 29 / 35 28 / 35 28 / 34 28 / 34 Variable frequency
Centrifugal force high / low amp ( kN )
277 / 206 277 / 206 325 / 236 335 / 260 400 / 300 460 / 340 Variable kN
Make Cummins Cummins Cummins Cummins Cummins Cummins Cummins Model 4 BTA 3.9-C116 4 BTA 3.9-C116 QSB 4.5-C160 QSB 4.5-C160 QSB6,7-C220 QSB6.7-C220 QSB 3.3-C99 Net power ( kW @ rpm ) 87 86 @ 2200 119 @ 2200 119 @ 2200 164 @ 2200 164 @ 2200 86 @ 2200 Length ( mm ) 5630 5630 5900 5900 6300 6300 5780 Width ( mm ) 2250 2250 2258 2258 2500 2500 2258 Height ( mm ) 3027 3027 3075 3075 3265 3265 3070 Turning circle radius ( mm ) - - - - - - - Distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment
Make Ammann Dynapac Dynapac Dynapac Dynapac Dynapac Dynapac Model ARS 122 CA15PD CA25PD CA30PD CA35PD DRS120PD CA300PD Operating weight ( kg ) 11200 - 13180 7000 10500 11300 12300 12800 12500
Type
Smooth drum / PD shell
Pad Foot Pad Foot Pad Foot Pad Foot Pad Foot Pad Foot
Drum
Drum width ( mm ) 2130 1680 2130 2130 2130 2130 2130
Compaction Engine
Dimensions
Number of pads - 84 130 130 150 130 150 Pad area ( cm2 ) - - - - - - - Nominal amplitude 1,85 / 1,15 1,7 / 0,8 1,8 / 0,9 1,8 / 0,9 1,7 / 0,8 1,8 / 0,9 1,7 / 0,8 Vibration frequency ( Hz ) 32 / 35 32 33 33 33 33 33
Centrifugal force high / low amp ( kN )
277 / 206 114 / 55 250 / 123 250 / 123 250 / 123 250 / 130 300 / 146
Make Cummins Kubota Cummins Cummins Cummins Dynapac Cummins Model 4 BTA 3.9-C99 V3307 4BT3,9 QSF3,8 QSF3,8 4CylWT 4BTA Net power ( kW @ rpm ) 74 @ 2200 55 / 2200 74 / 2300 97 / 2500 97 / 2500 79 / 2200 82 / 2200 Length ( mm ) 5460 4510 5560 5560 5560 5600 5550 Width ( mm ) 2260 1870 2256 2256 2276 2260 2384 Height ( mm ) 3030 2700 2890 2890 2890 2977 2990 Turning circle radius ( mm ) - - - - - - - Distributor ELB Equipment Dynapac Dynapac Dynapac Dynapac Dynapac Dynapac
Make Dynapac Dynapac Hamm Hamm Hamm Hamm Hamm Model CA510PD CA 610PD 3410P 3411P 3412P 3414P 3516P Operating weight ( kg ) 18300 20700 11015 11795 12300 14340 15855 Type Pad Foot Pad Foot Pivoted Pivoted Pivoted Pivoted Pivoted
Drum
Drum width ( mm ) 2130 2130 2140 2140 2140 2140 2140
Compaction Engine
Dimensions
Number of pads 150 150 140 140 140 140 140 Pad area ( cm2 ) - - - - - - - Nominal amplitude 1,8 / 1,1 1,8 / 1,1 1,61 / 0,68 1,61 / 0,68 1,87 / 0,88 1,90 / 0,90 1,86 / 0,88 Vibration frequency ( Hz ) 29 / 31 29 / 31 30 / 40 30 / 40 30 / 40 30 / 40 30 / 40
Centrifugal force high / low amp ( kN )
317 / 231 317 / 231 211 / 158 211 / 158 256 / 215 256 / 215 256 / 215
Make Cummins Cummins DEUTZ DEUTZ DEUTZ DEUTZ DEUTZ Model 6BTA QSB6,7 TCD 2012 L04 TCD 2012 L04 TCD 2012 L04 TCD 2012 L04 TCD 2012 L06 2V Net power ( kW @ rpm ) 127 / 2200 129 / 2200 100 @ 2300 100 @ 2300 100 @ 2300 100 @ 2300 155 @ 2300 Length ( mm ) 6180 6180 5695 5695 5750 5705 6075 Width ( mm ) 2400 2400 2250 2140 2140 2250 2270 Height ( mm ) 3000 3000 3040 3040 3010 3010 3010 Turning circle radius ( mm ) - - 4005 4005 3690 3690 4360 Distributor Dynapac Dynapac Wirtgen SA Wirtgen SA Wirtgen SA Wirtgen SA Wirtgen SA
www . equipmentandhire . co . za
EQUIPMENT SPECS HANDBOOK 2021 / 2022
47
