Excavators |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Backhoe Engine
Dimensions
Make Hidromek Hidromek Hidromek Hitachi Hitachi Hitachi Hitachi Hitachi Model HMK310LC H4 HMK390 LC H4 HMK500LC H4 ZX55U-5A ZX65USB ZX130-5G ZX200-5G ZX240-5G Operating mass ( kg ) 32100 39800 51800 5200 6470 12400 19800 23400 Std bucket capacity ( SAE heaped ) ( m3 ) 1,6 2,2 3,2 0,15 0,21 0,59 0,9 1,1 Reach at ground level ( mm ) 9790 9810 10490 5820 6080 7800 9430 9880 Max digging depth ( mm ) 6360 6560 6480 3530 3770 5120 6180 6500 Max dumping height ( mm ) 6870 6870 6940 4070 4170 5990 6830 6990
Bucket breakout ( curling ) force ( SAE rated ) ( kN )
17,900 22,100 27,600 32,1 35,9 91 141 163 Make Isuzu Isuzu Isuzu Yanmar Yanmar Isuzu Isuzu Isuzu Model
Isuzu AQ- 6HK1X
Isuzu AQ- 6HK1X
Isuzu AQ- 6UZ1X
EDM-4TNV88
4TNV94L- ZWHB
CC-4BG1T CC-6BG1T CC-6BG1T
Net power ( kW @ rpm ) ( SAE J1349 ) 151 @ 1800 200 @ 1900 270 @ 2000 28,2 @ 2400 34,1 @ 2000 66 @ 2150 125 @ 2100 132 @ 2150 Length ( transport position ) ( mm ) 7540 6670 7590 5470 5790 7700 9750 10360 Width ( overall ) ( mm ) 3200 3300 3500 2000 2000 2490 2800 2990 Ground clearance ( mm ) 500 505 600 340 335 410 450 460 Track length on ground ( mm ) 4950 5190 7590 2000 1990 2880 4170 4260 Max speed ( km / hour ) 5,1 5 4,7 4,2 4,8 5,5 5,5 5,5 Tail swing radius ( mm ) 3260 3560 3915 1100 1300 2190 2890 3140
Distributor
Maximum Equipment
Maximum Equipment
Maximum Equipment
Hitachi Hitachi Hitachi Hitachi Hitachi
Backhoe Engine
Dimensions
Make Hitachi Hitachi Hitachi Hitachi Hitachi Hitachi Hitachi Hitachi Model ZX870LCR-5G EX1200-7 BE EX1900-6 EX2000-7 EX2600-7 EX3600-7 EX5600-7 EX8000-7 Operating mass ( kg ) 84200 117000 192000 193000 256000 366000 545000 839000 Std bucket capacity ( SAE heaped ) ( m3 ) 4,5 7 12 12 17 22 34 43-48 Reach at ground level ( mm ) 12020 13410 14770 14870 16050 17660 19400 21400 Max digging depth ( mm ) 7140 8100 8180 8090 8250 8630 8800 8400 Max dumping height ( mm ) 8130 8010 9060 9360 10100 11540 12200 11900
Bucket breakout ( curling ) force ( SAE rated ) ( kN )
411 569 671 701 830 1050 1480 2020 Make Isuzu Cummins Cummins Cummins Cummins / MTU Cummins / MTU Cummins / MTU Cummins / MTU
Model
BB- 6WG1XQA-04
QSK23-C QSKTA38-CE QST30-C
Net power ( kW @ rpm ) ( SAE J1349 ) 360 @ 1800 567 @ 1800 810 @ 1800 746 @ 1800
QSKTA50-CE / 12V4000 C13R
1119 @ 1800 / 1150 @ 1800
QSKTA60-CE / 12V4000 C33
1450 @ 1800
2 x QSKTA50- CE / 2 x 12V4000 CR13
2 x 1119 @ 1800
Length ( transport position ) ( mm ) 14800 14580 9730 9770 10325 11200 12535 13460 Width ( overall ) ( mm ) 4450 5470 6660 7265 8040 9420 10300 11460 Ground clearance ( mm ) 890 1020 795 795 770 905 1100 1250 Track length on ground ( mm ) 6360 6500 7480 7480 7870 8700 9350 10500 Max speed ( km / hour ) 4,5 3,5 2,8 2,8 2,3 2,2 2,3 2 Tail swing radius ( mm ) 4600 4900 6035 6115 6490 6980 7970 8480 Distributor Hitachi Hitachi Hitachi Hitachi Hitachi Hitachi Hitachi Hitachi
2 x QSKTA60- CE / 2 x 12V4000 C33
2 x 1450 @ 1800
Backhoe Engine
Dimensions
Make Hyundai Hyundai Hyundai Hyundai Hyundai Hyundai Hyundai Hyundai Model 210 Smart HX220S R220LC-9S R260LC-9S HX300SL R300LC-9S R330LC-9S R380LC-9SH Operating mass ( kg ) 21 200 21 260 21900 25200 30200 29700 32700 38400 Std bucket capacity ( SAE heaped ) ( m3 ) 0,92 1,2 1,2 1,46 1,49 1,49 1,44 1,62 Reach at ground level ( mm ) 9330 9820 8960 9360 9820 9820 10110 10490 Max digging depth ( mm ) 6220 6730 5820 6450 6380 6440 6370 6820 Max dumping height ( mm ) 6520 6780 6330 6420 6990 6940 7050 7370
Bucket breakout ( curling ) force ( SAE rated ) ( kN )
133,4 - 133,4 156,9 180,4 168,7 189,3 201 Make Cummins Hyundai Hyundai Hyundai Hyundai Cummins Hyundai Hyundai Model 6BT5.9-C HM5.9 HM5.9 HM 5.9 HM8.3 C8.3-C HM 8.3 D6AC-C
Net power ( kW @ rpm ) ( SAE J1349 ) 101 @ 2000 108 @ 2000 107 @ 1950 121 @ 2000 183 @ 2200 188 @ 1900 196 @ 1900 195 @ 1900 Length ( transport position ) ( mm ) 9 570 9 530 9 650 10 050 10 900 10 850 11 230 11 240 Width ( overall ) ( mm ) 2800 2990 2800 3180 3200 3200 3280 3340 Ground clearance ( mm ) 480 470 480 480 500 500 500 550 Track length on ground ( mm ) 4 160 4 440 4 114 4 640 4 940 4 940 4 940 5 280 Max speed ( km / hour ) 5,3 5,7 5,5 5,8 6,1 6 5,8 5 Tail swing radius ( mm ) 2830 2845 2840 2975 3345 3345 3380 3425 Distributor HPE Africa HPE Africa HPE Africa HPE Africa HPE Africa HPE Africa HPE Africa HPE Africa
14 EQUIPMENT SPECS HANDBOOK 2021 / 2022 www . equipmentandhire . co . za
