PAllet RACking
ShelviNG
n
n
n
n
n
Quick & easy to install
Easy to specify range of starter & extension bays
Frames are pierced on a 75mm pitch to
allow for positioning of beams
Maximum beam pitch of 1725mm
Beam loads are 2000kg per pair
Uniformly Distributed Loads
n
n
n
n
Pallet loads are assumed to be 1000kg each
All bays are supplied with floor fixings
Beam locking pins prevent accidental displacement
of beams by mechanical handling equipment
Frames are of bolted construction & supplied
assembled with painted graphite grey uprights &
galvanised cross braces. Beams are painted yellow
Overall Size
H x W x D mm
Beam
Levels
Starter Bay
Model
Price
Extension Bay
Model
Price
2500mm Wide Bays - Carries two 1000W x 1000/1200D mm pallets
2
PS22930
£413.16
PE22930
£290.54
4800 x 2250 x 900
3
PS22948
£603.54
PE22948
£426.68
6000 x 2250 x 900
4
PS22960
£757.83
PE22960
£544.76
3000 x 2250 x 1100
2
PS221130
£420.58
PE221130
£294.25
4800 x 2250 x 1100
3
PS221148
£613.90
PE221148
£431.85
6000 x 2250 x 1100
4
PS221160
£770.14
PE221160
£550.92
2700mm Wide Bays - Carries two 1200W x 1000/1200D mm pallets
3000 x 2700 x 900
2
PS27930
£473.47
PE27930
£350.86
4800 x 2700 x 900
3
PS27948
£694.01
PE27948
£517.14
6000 x 2700 x 900
4
PS27960
£878.46
PE27960
£665.39
3000 x 2700 x 1100
2
PS271130
£480.89
PE271130
£354.57
4800 x 2700 x 1100
3
PS271148
£704.37
PE271148
£522.32
6000 x 2700 x 1100
4
PS271160
£890.77
PE271160
£671.54
eXtRA BeAM levels
Bay Width
Model
Price
2250
PL229
£81.88
2700
Pair of beams and locking clips
PL279
£112.04
gAlvAniseD steel
DeCking
Overall Size
W x D mm
Model
Price
Converts a beam level into
shelving. (2000kg UDSWL)
2250 x 900
PSL2290
£94.49
2250 x 1100
PSL2211
£110.01
2700 x 900
PSL2790
£131.59
2700 x 1100
PSL2711
£200.13
47
ShelviNG & StORaGe
3000 x 2250 x 900
