PRODUCTION DE L’ALUMINIUM // ALUMINIUM PRODUCTION

Real-time Vibrated Bulk Density (VBD)
measurement by image analysis
MESURE EN TEMPS RÉEL DE LA DENSITÉ APPARENTE EN VIBRATION (VBD) PAR IMAGERIE

19

Mesure en temps réel de la densité apparente en
REAL-TIME VIBRATED BULK DENSITY (VBD) MEASUREMENT BY IMAGE ANALYSIS
vibration (VBD) par imagerie
Wilinthon Bogoya-Forero1, Carl Duchesne1 et Jayson Tessier2
1

2

Centre de recherche sur l’aluminium – REGAL, Département de Génie Chimique,
Université Laval, Québec, QC, G1V 0A6, Canada

Alcoa Canada Primary Metals, Aluminerie de Deschambault, 1 Boulevard des Sources,
Deschambault - Grondines, QC, G0A 1S0, Canada

1. Introduction

5. Experimental

• Petroleum coke is a byproduct of the refining of crude oil and is
considered by the refineries a waste product.

• Evaluate the effect of coke type and particle size
distribution on the texture by image analysis to estimate
the VBD.

• For the aluminum industry, however, petroleum coke is an essential raw
material for the production of anodes (Fig. 1).

MIXED COKE
• Effect of the proportion of sponge cokes (A & E).

UNMIXED COKE

• Five sponge cokes (A-E) were classified as shown in table 1.
VBD apparatus

Table 1. Particle size distribution
Fig 1. Schematic of the baked anode manufacturing process



The coke porosity is a key factor in optimizing pitch demand and anode
density.

2. Problem

Size
Opening (mm)
class
1
2,38 – 4,75
Coarse
2
1,41 - 2,38
3
0.6 - 1,41
4
0,3 - 0,6
Intermediate
5
0,15 - 0,3
6
0,074 -
