LAMPS AND COMPONENTS
www.elmarkholding.eu
LED STRIPS AND PROFILES
LED MODULES
99LEDMOD2430
99LEDMOD2440
99LEDMOD2460
LED MODULES
99LEDMOD1230
99LEDMOD1240
99LEDMOD1260
883
IP20 230V AC
Catalogue number Watt
(W) Lumen
(lm) Colour temp.
(K) Length
(mm) Height
(mm) Packing/Box
(pcs)
99LEDMOD1230 12 1140 3000 63 63 1/100
99LEDMOD1240 12 1140 4000 63 63 1/100
99LEDMOD1260 12 1140 6000 63 63 1/100
99LEDMOD2430 24 2280 3000 120 63 1/80
99LEDMOD2440 24 2280 4000 120 63 1/80
99LEDMOD2460 24 2280 6000 120 63 1/80
LED Chip: Epistar | Lens angle: 160°| Mounting: With magnet, for the lamps with iron plates, the modules have magnets that can be attached to the installation.
For the plastic lamps, the modules have double-sided conductive adhesive tape, which can be pasted and installed.
Aplication: Suitable for ceiling lamp, wall lamp ,Bulkhead light etc.
Ra>80
3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
LED MODULES EPISTAR
