LAMPS AND COMPONENTS
LED STRIPS AND PROFILES
www.elmarkholding.eu
LED 600 24V DC - IP20
99LED864
99LED865
99LED868
99LED869
99LED870
99LED871
LED 600 24V DC - IP65
880
IP20
99LED872
99LED873
99LED876
99LED877
99LED878
99LED879
IP65 24V DC
LED 600
Catalogue number Model LEDs
(pcs/m) Watts / meter Colour temp. (K) Colour of light Protection
rating Packing/Box
(pcs)
99LED864 LED-3528-120-WW * 120pcs/m 9.6W/M 2700-3000 warm white IP 20 5/100
99LED865 LED-3528-120-CW * 120pcs/m 9.6W/M 6200-6500 cold white IP 20 5/100
99LED868 LED-3528-120-Y * 120pcs/m 9.6W/M 587-592 yellow IP 20 5/100
99LED869 LED-3528-120-G * 120pcs/m 9.6W/M 520-525 green IP 20 5/100
99LED870 LED-3528-120-B * 120pcs/m 9.6W/M 465-470 blue IP 20 5/100
99LED871 LED-3528-120-R * 120pcs/m 9.6W/M 620-630 red IP 20 5/100
99LED872 LED-3528-120-WW * 120pcs/m 9.6W/M 2700-3000 warm white IP 65 5/100
99LED873 LED-3528-120-CW * 120pcs/m 9.6W/M 6200-6500 cold white IP 65 5/100
99LED876 LED-3528-120-Y * 120pcs/m 9.6W/M 587-592 yellow IP 65 5/50
99LED877 LED-3528-120-G * 120pcs/m 9.6W/M 520-525 green IP 65 5/50
99LED878 LED-3528-120-B * 120pcs/m 9.6W/M 465-470 blue IP 65 5/50
99LED879 LED-3528-120-R * 120pcs/m 9.6W/M 620-630 red IP 65 5/50
* Luminous efficiency: 22-24 lm/LED, with 3M adhere attached, mark cut.
** Luminous efficiency: 22-24 lm/LED, with 3M adhere attached, mark cut.
24
DC
SMD
5050
SMD
3528
REEL
5m
120
3
4+1
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
