LAMPS AND COMPONENTS
www.elmarkholding.eu
LED STRIPS AND PROFILES
LED 150 RGB 12V DC STELLAR IP20
99XLED311
99XLED316
LED 300 12V DC STELLAR IP20
99XLED306
99XLED305
99XLED312
99XLED313
IP20
873
IP65 12V DC
Catalogue number Model LEDs
(pcs/m) Watts / meter Colour temp. (K) Colour of light Protection
rating Packing/Box
(pcs)
99XLED311 LED- 5050 * 30pcs/m 7.2 W/M - RGB IP 20 5/20
99XLED316 LED- 5050* 30pcs/m 7.2W/M RGB IP65 5/20
99XLED306 LED- 3528-60WW *** 60pcs/m 4.8W/M 2700-3000K warm white IP 20 5/20
99XLED305 LED- 3528-60CW *** 60pcs/m 4.8W/M 6000-6500K cold white IP 20 5/20
99XLED312 LED- 3528-60CW *** 60pcs/m 4.8W/M 6000-6500 cold white IP65 5/20
99XLED313 LED- 3528-60WW *** 60pcs/m 4.8W/M 2700-3000 warm white IP65 5/20
* Flex white FCB, 10mm, double layer, mark cut
** Luminous efficiency: 10-12 lm/LED, 10mm Flex white FCB, double layer, mark cut
*** Luminous efficiency: 3-4 lm/LED, 8mm Flex yellow PCB, single layer, mark cut
**** Luminous efficiency: 3-4 lm/LED, 8mm Flex white FCB, double layer, mark cut
DC
SMD
5050
REEL
5m
2+0
120
standard
+extended
2
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
LED 150 RGB / 300 STELLAR
