ELMARK Lighting 2019 Lighting_2019 | Page 440

LAMPS AND COMPONENTS
LAMPS
www.elmarkholding.eu
LED PEAR A60 LED PEAR A65 LED PEAR A80
99LED818
99LED819
99LED797 99LED850WW
99LED850W
99LED850CW 99LED908
99LED909
99LED909CW
99LED722
LED PEAR A60
LED PEAR A60 DIMMABLE
99LED588
99LED587
99LED821
99LED582
99LED581
IP20
840
LED PEAR
Catalogue number Dimmable Watt
(W) LED lamp lumens Colour temp.
(lm)
(K) Beam angle Length
(mm) Diameter
(mm) Packing/Box
(pcs)
99LED588 - 12 1080 4000 240° 127 60 1/100
99LED587 - 12 1080 2700 240° 127 60 1/100
99LED821 - 12 1080 6400 240° 127 60 1/100
99LED582 Yes 12 1080 4000 180° 127 60 1/60
99LED581 Yes 12 1080 2700 180° 127 60 1/60
99LED818 15 1500 4000 180° 115 60 1/100
99LED819 15 1500 2700 180° 115 60 1/100
99LED797 15 1500 6400 180° 115 60 1/100
99LED722
15* 1200 2700 160° 153 80 1/100
99LED850WW - 18 1700 2700 180° 133 65 1/100
99LED850W - 18 1700 4000 180° 133 65 1/100
99LED850CW - 18 1700 6400 180° 133 65 1/100
99LED908 - 20 1800 4000 180° 153 80 1/50
99LED909 - 20 1800 2700 180° 153 80 1/50
99LED909CW - 20 1800 6400 180° 153 80 1/50
*Until supplay last
50/60
Hz
SMD
2835
Ra>80
>20000
3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
